| Accuracy |
+/-3-2-3% |
| Process Connection Location |
Bottom |
| Process Connection Type |
NPT |
| Application |
Compressors, Hydraulics, Marine, Pumps |
| Gauge Case Material |
ABS |
| Series |
113.13 |
| Lens Material |
Plastic |
| Primary Pressure Range |
0 to 60 psi |
| Primary Scale Units |
psi |
| IP/NEMA Rating |
IP65 |
| Liquid-Filled Case |
Yes |
| Hazardous Location Rating |
Not Rated |
| Panel-Mountable |
No |
| Blowout Safety Back |
No |
| Calibration Certificate Included |
No |
| Graduations |
20 psi |
| Gauge Filled With |
Glycerin |
| Case Color |
Black |
| Gauge Primary Range Numbered Graduations |
10 |
| Gauge Special Options |
Heavy Duty |
| For Use With |
Brass, Industrial Applications, Media Compatible with Copper Alloy |
| Smallest Graduation |
2 psi |
| Gauge Secondary Range Values |
0 to 60 |
| Gauge Primary Range Smallest Graduation |
10 |
| Characteristics |
With Brass Internals |
| Gauge Application |
General-Purpose Case |
| Includes |
Vent Plug |
| Socket Material |
Brass |
| Connection Type |
MNPT |
| Standards |
EN 837-1 |
| Compatible Process Media |
Liquids and Gases |
| Ambient Operating Temperature Range |
-4 Degrees to 140 Degrees F (-20 Degrees to 60 Degrees C) |
| Primary Scale Minor Graduations |
10 |
| Pressure Gauge Type |
General Purpose Dial Pressure Gauge |
| Pressure Range Type |
Pressure |
| Dial Face Material |
ABS |
| Dial Color |
White |
| Accuracy Scale |
Mid-Scale |
| Sensor Type |
Bourdon Tube |
| Process Connection Gender |
Male |
| Gauge Case Liquid |
Glycerin |
| Dry Dampening Feature |
None |
| Pointer Material |
ABS |
| Accuracy Grade |
ASME B40.100 Grade B |
| Sensor Material |
Bronze |
| Secondary Scale Units |
kPa |
| Freeze Resistant Movement |
No |
| Includes Vent Plug |
Yes |
| Vibration Resistance |
Liquid-Filled |
| Non-Sparking |
No |
| Field Fillable |
No |
| Includes Calibration Certificate |
No |
| Primary Scale Numeric Increments |
10 |
| Pointer Color |
Black |
| Secondary Pressure Range |
0 to 410 kPa |
| Includes Mounting Hardware |
No |
| Removable Bezel |
No |
| Scale Type |
Dual |
| Case Construction |
Welded Joint |
| Cleaned for Oxygen Service |
No |
| Maximum Pressure |
60 |
| Operating Temperature Range |
-4 Degrees to 140 Degrees F |
