Welch 2037B-01 Vacuum Pump 1/5 hp Output Power, 1.8 cfm Free Air Displacement, 28.5 in Hg Max Vacuum - KVM Tools Inc.KV5JMT4

Welch 2037B-01 Vacuum Pump 1/5 hp Output Power, 1.8 cfm Free Air Displacement, 28.5 in Hg Max Vacuum

UPC: 155752100697 | Harmonization / Schedule B : 8414.10.0000

Country of Origin: United States | Shipping Weight: 22.7 lbs

$4,150.57 - $4,150.57
$4,150.57
$4,150.57 - $4,150.57
$4,150.57
Vacuum Pump, Output Power 1/5 hp, Voltage 115V AC, Free Air Displacement 1.8 cfm, Maximum Vacuum 28.5 in Hg, Vacuum Pressure 47 mbar, Inlet Size 1/4 in, Inlet Type NPT, Outlet Size 1/4 in, Outlet Type Hose Barb, Application Resin Transfer Molding, Phase Single
Item Vacuum Pump
HP 1/5 hp
Voltage 115V AC
Phase Single
Amps AC 1.3
Weight 21.3 lb
Displacement 1.8 cfm
End Vacuum 28.5 in Hg
Max. dBA 56
NPT Inlet 1/4 in
Motor Type IP21
Ultimate Pressure Torr 35
RPM 1,725 RPM
Filter Yes
Hz 60
Valve Type Bleed
Ballast Yes
Application Resin Transfer Molding
Includes 115V Plug
Finish Paint
Current Rating 1.3 A
Maximum Speed 1,725 RPM
Inlet Type NPT
Output Power 1/5 hp
Maximum Vacuum 28.5 in Hg
Outlet Type Hose Barb
Vacuum Pressure 47 mbar
Wattage 150 W
Free Air Displacement 1.8 cfm
Frequency 60 Hz
