| For Use With |
All CFC, HFC, and HCFC Non-Flammable Refrigerants Including R12, R22, R134a, R404a, R410a, R502, R507 and Many Others |
| Includes |
Carrying Case, Sensor Filters |
| Lamp |
Yes |
| Function |
Leak Detection |
| Application |
Refrigerant Leak Detection |
| Sensitivity per Year |
0.05 oz/yr R-134a, 0.025 oz/yr R-22 |
| Features |
Ambient Level Reset, Automatic Calibration, Digital Numeric Leak Size Detector, Solid Electolyte Semiconductor Sensor, Splash Resistant, Visual LED Leak Alarm, Worklight |
| Sensitivity Level |
3 |
| Compatible With |
All CFC, HCFC and HFC Refrigerants |
| Design |
Ergonomic with a Rubber Cushion Grip Handle |
| Carton Quantity |
1 |
| Sensor Life |
300 hr |
| Battery Type |
AA |
| Power Source |
Battery |
| Standards |
ASHRAE 173-2012, CE Certified, EN 14624, SAE J2791, SAE J2913 |
| Product Type |
Refrigerant Leak Detector |
| Includes Low Battery Warning |
Low Battery Warning Included |
| Indication Method |
Audio/Visual |
| A2L Compatibility |
A2L Compatible |
| For Refrigerant Type |
R-1234YF, R-134A, R-22 |
| Includes Batteries |
Batteries Included |
| Sensitivity - R410a |
0.05 oz/yr |
| Number of Sensitivity Levels |
3 |
| Operating Temperature - Maximum |
125 Degrees F |
| Mobility |
Handheld |
| Warranty |
2 yr |
| Detects Trace Gas |
Trace Gas Detected |
| Sensitivity - R22 |
0.025 oz/yr |
| Operating Temperature - Minimum |
-24 Degrees F |
| Calibration |
Automatic |
| Sensor Type |
Heated Diode |
| For Refrigerant Group |
CFC, HCFC, HFC |
| Sensitivity - General |
0.05 oz/yr |
| Number of Batteries |
4 |
| Response Time |
1 sec |
| Operating Humidity - Maximum |
95 % |
| Operating Mode |
Pinpoint |
| Includes Lamp |
Lamp Included |
| Warm-Up Time |
200 sec |
| Display Type |
Digital |
