| Item |
Surge Protector Outlet Strip |
| Number of Outlets |
6 |
| Voltage |
120V AC |
| Color |
Black |
| Number of Conductors |
3 |
| Gauge/Conductor |
14/3 |
| Max. Amps |
15 A |
| Mounting Style |
Keyhole |
| Power Indicator |
Yes |
| Housing Material |
Plastic |
| NEMA Receptacle Configuration |
5-15R |
| NEMA Plug Configuration |
5-15P |
| Number of Transformer Outlets |
1 |
| Hz |
50/60 Hz |
| For Use With |
Desktop, Network Or Home Computing Application Requiring AC Protection |
| Includes |
(6) Safety Covers, Instruction Manual with Warranty Information |
| Coax Surge Protection |
No |
| Standards |
Approvals RoHS, cUL / CSA (Canada), Exceeds IEEE 587 category A&B specifications, UL1363 (Power Tap), UL1449 3rd Edition (AC Suppression) |
| NEC Cord Designation |
SJT |
| Circuit Breaker |
No |
| Rated Joules |
790 |
| Medical Grade |
No |
| Outlet Center Distance |
28.5mm |
| Max. Surge Current |
35.5 kA |
| Medical Facility Use |
Outside Patient Care Areas (UL 1363) |
| Communication Port |
None |
| Application |
Home and Office |
| Receptacle Configuration |
NEMA 5-15R |
| USB Charging Port |
0 |
| Plug Configuration |
NEMA 5-15P |
| Total Number of Outlets |
6 |
| Trade Designation |
SJT |
| Product Type |
Surge Protector Outlet Strip |
| Right-Angle Plug |
No |
| Recommended Electrical Service |
120V (110-125V) |
| Outlets Measurement (Center to Center) |
28.5mm |
| EMI / RFI Filtering |
Yes |
| Package Includes |
TLP606B Protect It! 6-Outlet Surge Protector, Black Housing;Owner's manual |
| Voltage Compatibility (VAC) |
120 |
| Input Cord Details |
SJT |
| Protection Modes |
Includes full normal mode (H-N) and common mode (N-G / H-G) line suppression |
| AC Suppression Response Time |
< 1 ns |
| Receptacle Color |
Black |
| Input Plug Type |
NEMA 5-15P |
| Transformer Accommodation |
(2) Yes |
| Maximum Surge Amps |
35500 |
| AC Suppression Joule Rating |
790 |
| Housing Color |
Black |
| Product Certifications |
CAN/CSA-C22.2 No. 269.3 (Canada); CAN/CSA-C22.2 No. 308 (Canada); cUL Listed; UL 1449; UL 1363; UL Listed |
| Outlet Orientation |
Single row of 6 outlets |
| Slot or Hole Mount Measurement (Center to Center) |
Distance between slots = 101 mm; Distance between slot height = 28 mm |
| Circuit Breaker (amps) |
15 |
| Diagnostic LED Details |
Built-in LED confirms suppressor "protection present" (green) status |
| Material of Construction |
Plastic |
| Automatic Shut-Off |
Yes |
| Power Cord Color |
Black |
| Output Receptacles |
(6) 5-15R |
| Switches |
Combination AC circuit breaker and 2 position red illuminated on/off power switch |
| Overload Protection |
15A resettable illuminated combo switch / circuit breaker |
| Frequency Compatibility |
50 / 60 Hz |
| Nominal Input Voltage(s) Supported |
120V AC |
| Diagnostic LED(s) |
Yes |
| Network (Ethernet) Protection |
No |
| Input Cord Gauge Type |
14 gauge; SJT |
| Mounting Holes or Slots |
Yes |
| Input Cord Gauge (AWG) |
14 |
| Package Quantity |
1 |
