| Material |
Copper |
| Color Code |
Ruby |
| Color |
Ruby |
| Wire Gauge |
3/0 AWG |
| Die Code |
60 |
| Standards |
CSA Certified, UL Listed |
| Voltage Rating |
35 kV |
| Compatible with Product Type |
Copper Conductor |
| Maximum Conductors |
1 |
| Contact Material |
Aluminum |
| Special Features |
For Aluminum and Copper Concentric Conductors and Compact Code Aluminum Strandings |
| For Conductor Material |
Aluminum |
| Maximum Operating Temperature |
194 Degrees F |
| RoHS Compliant |
Yes |
| Contact Finish |
Tin |
| Termination Style |
Crimp |
| Barrel Finish |
Tin Plated |
| Seam Style |
Seamless |
| For Wire Type |
Stranded |
| Number of Crimps |
2 |
| Maximum Voltage |
35 kV |
| Features |
For aluminum and copper concentric conductors and compact code aluminum strandings.; Connectors supplied with T&B Oxide inhibitor compound in wire bore.; Permits aluminum conductors to be spliced to copper or aluminum conductors.; Application Tools: TBM5, TBM5S, TBM6, TBM6S, TBM8, TBM8S |
| Special Functions |
For aluminum and copper concentric conductors and compact code aluminum strandings. |
| Product Type |
Aluminum Splice |
| Insulation Material |
None |
| Number of Batteries |
0 |
| Surface Finishing |
Tin Plated |
| Temperature Range |
90°C |
| Product Name |
ELECTRICAL SPLICE |
| Type of connection |
End connector |
| Voltage level |
Up to 35 kV |
| Standard |
UL E9809 |
| AWG-range |
3/0-3/0 |
| Temperature Rating |
90 C |
