Square D QOB3701021 Miniature Circuit Breaker

Square D QOB3701021 Miniature Circuit Breaker, 70 A, 120/240V AC, 3-Pole, Shunt Trip, 10kA, Bolt-On

UPC: 785901031031 | Harmonization / Schedule B : 8536.20.0020

Country of Origin: Mexico | Shipping Weight: 1.5 lbs

$748.64 - $748.64
$748.64
$748.64 - $748.64
$748.64

Miniature Circuit Breaker, Amps 70 A, AC Voltage Rating 120/240V AC, Circuit Breaker Type Shunt Trip, Number of Poles 3, DC Voltage Rating 48V DC, Circuit Breaker Actuator Paddle, Circuit Breaker Mounting Style Bolt On, Compatible Panelboard/Load Center Series QO, Phase Three, Series QOB, Max. AIR Rating 10kA at 120/240V AC, For Use With Square D NQOD Panelboards, Terminal Connection Lug, Frame Size 100A/QO, Length 3.12 in, Width 3 in, Depth 2.91 in, Min. Operating Temp. 77 Degrees F

Series QO
Amps 70A
Number of Poles 3
AC Voltage Rating 120/240V AC
Circuit Breaker Type Standard
Phase 3
Circuit Breaker Actuator Paddle
Circuit Breaker Mounting Style Bolt On
Max. AIR Rating 10kA at 120/240V AC
Trip Type Shunt Trip
Terminal Connection Lugs
DC Voltage Rating 48V DC
For Use With NQ Panelboards
Standards UL Listed
Interrupt Rating 10 kA at 120/240V AC
Application HACR rated Applications
Features Mercury Free
Compatible Panelboard/Load Center Series QO
Max. Operating Temp. 104 Degrees F
Min. Operating Temp. 77 Degrees F
Voltage 240VAC
Country of Origin Mexico
