Square D MGL26400 Molded Case Circuit Breaker, 400 A, 600V AC, 2 Pole, Lug In/Lug Out Mounting Style, MG Series
UPC: 785901507567 | Harmonization (Schedule B): 8536.20.0020
SKU KV56761067
Original price
$7,379.71
-
Original price
$7,379.71
Original price
$7,379.71
$7,379.71
-
$7,379.71
Current price
$7,379.71
Molded Case Circuit Breaker, 400 A Amps, AC Voltage Rating 600V AC, Max. AIR Rating 18kA at 600V AC, For Use With Equipment Gear, Series MG, High Amp Trip Setting 4,000 A, Low Amp Trip Setting 800 A, Circuit Breaker Type Standard, Number of Poles 2, DC Voltage Rating Not Rated, Terminal Connection Box Lug, Trip Type Electronic, Phase Single, Instantaneous Trip Adjustable, Phase Connection AC, Frame Size 800A/M, Circuit Breaker Mounting Style Lug In/Lug Out, Height 12.9 in, Width 8.3 in. 6NGX9
| Item | Molded Case Circuit Breaker |
| Amps | 400 A |
| AC Voltage Rating | 600V AC |
| DC Voltage Rating | Not Rated |
| Max. AIR Rating | 18kA at 600V AC |
| Terminal Connection | Box Lug |
| Series | MG |
| Number of Poles | 2 |
| Circuit Breaker Actuator | Toggle |
| Circuit Breaker Mounting Style | Lug In/Lug Out |
| Circuit Breaker Type | Standard |
| Standards | BS, CCC, CEI, CSA Certified, Federal Specification W-C-375B/GEN, IEC, NEMA, NMX, UL Listed, UNE, UTE, VDE |
| Phase | Single |
| For Use With | Equipment Gear |
| Mounting | Lug In/Lug Out |
| Phase Connection | AC |
| Instantaneous Trip | Adjustable |
| Low Amp Trip Setting | 800 A |
| High Amp Trip Setting | 4,000 A |
| Trip Type | Electronic |
| Color | Black |
| Interrupt Rating | 25 kA at 240V AC, 20 kA at 380/415V AC, 65 kA at 240V AC, 35 kA at 380/415/480V AC, 18 kA at 600V AC, 50 kA at 240V AC |
| Features | Mercury Free; PVC Free |
| Application | HACR rated Applications; Distribution |
| Package Quantity | 1 |
