SKF 99346 Wear Sleeve, For 88.82 mm to 88.98 mm Shaft Dia Range, 15.88 mm Wd on Shaft, 20.65 mm Overall Wd

SKF 99346 Wear Sleeve, For 88.82 mm to 88.98 mm Shaft Dia Range, 15.88 mm Wd on Shaft, 20.65 mm Overall Wd

UPC: 085311042475 | Harmonization / Schedule B : 8483.90.5090

Country of Origin: Mexico | Shipping Weight: 0.415 lbs

$106.80 - $106.80
$106.80
$106.80 - $106.80
$106.80

Wear Sleeve, For Shaft Size 88.82 to 88.98 mm, Material Stainless Steel, Flange Diameter 97.64 mm, Overall Width 20.65 mm, Wall Thickness 0.28 mm, Width on Shaft 15.88 mm, Application Heavy Industrial, Finish Chromium Plated, For Maximum Shaft Diameter 88.98 mm, For Minimum Shaft Diameter 88.82 mm, Maximum Temperature 225 Degrees F, Outside Diameter Tolerance +/-1.6 mm, System of Measurement Metric, Width Tolerance +/-0.8 mm

Shaft Dia. Range 3.497 to 3.503 in
Width on Shaft 15.88 mm
Flange Dia. 3.844 in
Installation Depth 1.347 in
Overall Width 20.65 mm
Width Tolerance +/-0.8 mm
For Minimum Shaft Diameter 88.82 mm
Flange Diameter 97.64 mm
Wall Thickness 0.28 mm
Outside Diameter Tolerance +/-1.6 mm
For Shaft Size 88.82 to 88.98 mm
For Maximum Shaft Diameter 88.98 mm
Sleeve Material Stainless Steel
System of Measurement Metric
Application Heavy Industrial
Maximum Temperature 225 Degrees F
Material Stainless Steel
Finish Chromium Plated
Country of Origin Mexico
