| Head Material |
Aluminum-Zinc Alloy |
| NEMA Rating |
1, 13, 2, 3, 4, 4X |
| Type of Operator |
40mm Mushroom Head |
| Color |
Black |
| Legend |
No Legend |
| Number of Operators |
1 |
| Item |
Push Button operator |
| Bezel Material |
Chrome Die Cast Aluminum |
| Standards |
CE, CSA, RoHS, UL |
| Basic Material |
Metal |
| Accessory Group |
B |
| IP Rating |
66 |
| Product Type |
Push Button Operator |
| Reset |
push-pull |
| Ambient Air Temperature For Storage |
-40-70°C |
| Electrical Composition Code |
C11 3 single front mounting || C15 1 single front mounting || C7 4 single front mounting || C8 4 single and double front mounting || C10 4 single and double front mounting |
| Shock Resistance |
30 gn 18 ms) half sine wave acceleration IEC 60068-2-27 || 50 gn 11 ms) half sine wave acceleration IEC 60068-2-27 |
| Protective Treatment |
TH |
| Shape Of Signaling Unit Head |
round |
| Head Type |
standard |
| Operator Profile |
black mushroom Ø 40 mm, unmarked |
| Ambient Air Temperature For Operation |
-40-70°C |
| Overvoltage Category |
class I IEC 60536 |
| Vibration Resistance |
5 gn 2-500 Hz)IEC 60068-2-6 |
| Nema Degree Of Protection |
NEMA 13 || NEMA 4X |
| Device Presentation |
basic element |
| Ik Degree Of Protection |
IK06 IEC 50102 |
| Product Certifications |
GL || LROS (Lloyds register of shipping) || UL Listed || DNV || CSA || BV |
| Mechanical Durability |
500000 cycles |
| Device Short Name |
ZB4 |
| Product Or Component Type |
head for non-illuminated push-button |
| Ip Degree Of Protection |
IP66 IEC 60529 || IP67 || IP69 || IP69K |
