| Voltage |
208V |
| Amps AC |
14.4 A |
| Temp. Range |
110 Degrees to 170 Degrees F |
| System of Measurement |
Inch |
| Item - Water Heaters |
Mini Tank Water Heater |
| Phase |
Single |
| Features |
Automatic Temperature Control |
| Fuel Type |
Electric |
| Recovery @ 120 F Rise |
10 gph |
| Tank Capacity |
10 gal |
| Total Watts |
3,000 W |
| Recovery @ 100 F Rise |
12 gph |
| Recovery @ 140 F Rise |
9 gph |
| Connection Location |
Side |
| Commercial / Residential |
Commercial |
| Tank Capacity - Plumbing |
10.0 gal |
| Compliance |
UL Certified; UL Standard 174; NC Compliant; ASHRAE Standards |
| Number of Elements |
1 |
| Industry Type |
Commercial |
| Max. Pressure |
150 psi |
| Residential / Commercial |
Commercial |
| Phase - Water Heaters |
1 |
| Includes |
Resistor Elements, Surface Mounted Thermostat |
| Water Heater Design |
Point-of-Use |
| Standards |
ASME, CSA Certified, UL Listed |
| Voltage - Water Heaters |
208 |
| Water Connection |
3/4 in NPT |
| Connection Type |
NPT |
| Vent Type |
Standard |
| Thermal Efficiency |
Not Rated |
| Operating Voltage |
208V |
| Thermostat Mounting |
Surface |
| Maximum Delivered Temperature |
170 Degrees F |
| Cold Inlet Type |
NPT |
| Maximum Water Pressure |
150 psi |
| Water Connection Location |
Side |
| Maximum Recovery Flow Rate |
30 gph @ 40 Degrees F |
| Environment |
Indoor |
| Minimum Delivered Temperature |
110 Degrees F |
| Market |
Commercial |
| Tank Outer Shell Material |
Steel |
| Power Consumption |
3,000 W |
| Included Valves |
Temperature and Pressure Relief |
| Current |
14.4 A |
| First Hour Rating |
Not Applicable |
| Mounting Type |
Wall Mounting |
| Tank Outer Shell Finish |
Porcelain Enamel |
| Recovery Rate @ Rise |
10 gph @ 120 Degrees F, 12 gph @ 100 Degrees F, 15 gph @ 80 Degrees F, 20 gph @ 60 Degrees F, 30 gph @ 40 Degrees F, 9 gph @ 140 Degrees F |
| Automatic Thermostat |
Yes |
| Hot Outlet Type |
NPT |
| Overheat Protection |
Yes |
| Tank Insulation Material |
Polyurethane |
