Redhat 8342G003 Solenoid Valve, 4-Way, 3/8 in Pipe Size, 120V AC, Watertight/Without Junction Box, Brass Body

Redhat 8342G003 Solenoid Valve, 4-Way, 3/8 in Pipe Size, 120V AC, Watertight/Without Junction Box, Brass Body

UPC: | Harmonization / Schedule B : 8481.80.9005

Country of Origin: United States | Shipping Weight: 2.55 lbs

$628.01 - $628.01
$628.01
$628.01 - $628.01
$628.01
For Media Air; Inert Gases; Light Oil; Water
Application Analytical and Diagnostic Equipment; Biofuel and Heating Systems; Dust Collector Systems; Heating Equipment; Refining Applications
Valve Type NAMUR Mount
Mounting Orientation Horizontal or Vertical
Operation Type Direct Acting
Valve Ways 4-Way
Valve Positions 2-Position
Body Material Brass
Seal Material NBR
Nominal Pipe Size 3/8 in
Inlet Connection Type NPTF
Outlet Connection Type NPTF
Voltage 120V AC
Wattage 20.1 W
Frequency 60 Hz
Electrical Connections 1/2" Conduit w/18" Leads
Coefficient of Volume (Cv) 0.7
Orifice Diameter 3/16 in
Min. Operating Pressure Differential 0 psi
Max. Operating Pressure Differential - Water 100 psi
Max. Operating Pressure Differential - Steam Not Rated
Max. Operating Pressure Differential - Light Oil 100 psi
Max. Operating Pressure Differential - Air/Inert Gas 125 psi
Max. Fluid Temperature 160 °F
Min. Ambient Temperature 32 °F
Max. Ambient Temperature 125 °F
Includes Seal Yes
Includes Coil Yes
Coil Enclosure Watertight; Without Junction Box
Coil Insulation Class F
Overall Height 4-7/16 in
Overall Length 2-15/16 in
Overall Width 2-9/16 in
Operating Environment Indoor; Outdoor
IP Rating IP66
NEMA Rating 1; 2; 3; 3S; 4; 4X
Standards CSA; UL Listed
Country of Origin USA
