Redhat 8221G005 Solenoid Valve, 2-Way, Normally Closed, 3/4 in Pipe Size, 110V AC/120V AC, Slow-Closing

Redhat 8221G005 Solenoid Valve, 2-Way, Normally Closed, 3/4 in Pipe Size, 110V AC/120V AC, Slow-Closing

UPC: | Harmonization / Schedule B : 8481.80.9005

Country of Origin: Mexico | Shipping Weight: 2.8 lbs

$487.62 - $487.62
$487.62
$487.62 - $487.62
$487.62

The ASCO 8221G005 is a pilot-operated, slow-closing solenoid valve that controls the flow of water and light oil in piping systems. It operates with a 2-way/2-position, normally closed configuration and includes the coil and seals necessary for installation. Maximum fluid temperature: 180°F; Cv: 3; differential pressure rating: 5-150 psi. Environmental rating: Corrosive, Hazardous, Indoor, Outdoor; watertight coil enclosure rated IP66 and multiple NEMA ratings (1, 2, 3, 3S, 4, 4X).

For Media Water
Valve Ways 2-Way
Valve Starting Configuration Normally Closed
Inlet Connection Type NPTF
Outlet Connection Type NPTF
Voltage 110V AC; 120V AC
Valve Type Slow-Closing
Operation Type Pilot Operated
Seal Material NBR
Operating Pressure Differential - Maximum 150 psi Hot Water, Water
Operating Pressure Differential - Minimum 5 psi Water
Coil Insulation Class F
Application Autoclave, Laundry, Molding, Sterilizers
IP Rating IP66
Coil Enclosure Without Junction Box, Watertight
Electrical Connections 1/2" Conduit w/18" Leads
Valve Design 2-Way/2-Position
Body Material Brass
Standards CSA, UL Listed
Wattage 6.1 W
Valve Positions 2-Position
Includes Coil Yes
Operating Pressure Differential Steam - Maximum Not Rated
Coefficient of Volume (Cv) 3
Operating Pressure Differential Light Oil - Maximum Not Rated
Operating Pressure Differential Air/Inert Gas - Maximum Not Rated
Operating Pressure Differential Hot Water - Maximum 150 psi
NEMA Enclosure Rating 1, 2, 3, 3S, 4, 4X
Operating Pressure Differential Water - Maximum 150 psi
Frequency 50 Hz, 60 Hz
Includes Seal Yes
Environmental Rating Corrosive, Hazardous, Indoor, Outdoor
Fluid Temperature - Maximum 180 Degrees F
Thread Type NPT
Orifice Diameter 3/4 in
Overall Height 4-9/16 in
Overall Length 2-15/16 in
Overall Width 3-7/16 in
Country of Origin Mexico
