Polaris ITG-6B Multitap Connector, 2 Port, Single-Sided Entry, 14 AWG – 6 AWG Wire Size, Gray

Polaris ITG-6B Multitap Connector, 2 Port, Single-Sided Entry, 14 AWG – 6 AWG Wire Size, Gray

UPC: | Harmonization / Schedule B : 8536.90.4000

Country of Origin: United States | Shipping Weight: 0.05 lbs

$28.09 - $28.09
$28.09
$28.09 - $28.09
$28.09

Insulated Multitap Connector, Body Material Aluminum Alloy, Color Black, Finish Plastisol, For Conductor Material Copper, For Stranded Copper Wire Size - Minimum 14 AWG, For Stranded Copper Wire Size - Maximum 6 AWG, Head Style Hex, Hex Size 1/8 in, Insulation Material Plastisol, Maximum Operating Temperature 194 Degrees F, Maximum Voltage 600 V, Number of Ports 2, RoHS Compliant Yes, Standards cULus, Connector Type Multi-Tap, Direct Burial Rated No, Overall Length 1.13 in, Overall Width 1.24 in

For Wire Size 6 AWG
Hex Size 1/8 in
Max. Conductor Size 6 AWG
Min. Conductor Size 14 AWG
Stud Size 1/8 in
Wire Size (Class B,C,D) 6-14 AWG - (Class K,M,I) 6-14 AWG
Width 1.2 in
Length 1.1 in
For Stranded Copper Wire Size - Maximum 6 AWG
Overall Length 1.13 in
For Stranded Copper Wire Size - Minimum 14 AWG
Overall Width 1.24 in
Dimensions L=1.130 - W=1.240 - H=1.370
Hex Wrench Size 1/8
Conductor Cu Size Range 6-14 AWG (CLASS B, C,D) 6-14 AWG (CLASS G, H,I,K,M, DLO)
Wire Rope Length 1.13 in
Connector Type Single-Sided Entry
Number of Ports 2
For Conductor Material Copper
Body Material Aluminum
Insulation Material Plastisol
Direct Burial Rated No
Head Style Hex
Finish Plastisol
Color Black
Maximum Operating Temperature 194 Degrees F
Standards cULus
Screw Material Aluminum
No. of Ports 2
Type Multi Cable
Max. Voltage 600 V
Material Plastisol
RoHS Compliant Yes
Maximum Voltage 600 V
Voltage Rating 600 V
Number Of Conductors 2
Temperature Rating 90° C
Environmental Conditions 90 C
Standard cULus
Wire Type B,C,D,K,M,I
Application Wire Termination
Wire Cable Class Class B, Class C, Class D, Class G, Class H, Class I, Class K, Class M, Class DLO
Cu Conductor Max Amp 75
Assortment Fine Stranded Wire Pre-Insulated Connectors
Conductors Count 2
Max Torque 45
Ul File No E186991
Env Temp Cold Temperature rated to -45C
Temp Rating 90C, 9CU
Ul Standard UL 486A/B
Country of Origin United States
