PIC PRO-201L-254P Pressure Gauge, 0 to 3000 psi, 1/4 in MNPT, Stainless Steel, Silver

Name: PIC PRO-201L-254P Pressure Gauge, 0 to 3000 psi, 1/4 in MNPT, Stainless Steel, Silver
Brand: PIC Gauges
Price: 31.35 USD
Availability: InStock

UPC: 810024360895 | Harmonization / Schedule B : 9026.20.0000

Country of Origin: China | Shipping Weight: 0.54 lbs

$31.35 - $31.35

$31.35

$31.35 - $31.35

$31.35

Industrial Pressure Gauge, Nominal Dial Size 2 1/2 in, Accuracy +/-2-1-2 Percent, Gauge Case Material Stainless Steel, Process Connection Type NPT, Process Connection Gender Male, Lens Material Polycarbonate, Process Connection Size 1/4 in, Field Fillable No, Process Connection Location Bottom, Case Color Metallic, IP/NEMA Rating Not Rated, Primary Pressure Range 0 to 3,000, Dry Dampening Feature None, Vibration Resistance Liquid-Filled, Dial Color White

Item	Industrial Pressure Gauge
Connection Location	Lower
For Use With	Hydraulic Applications, Media Compatible with Copper Alloy/Brass
Gauge Application	General Purpose
Includes	Vent Plug
Range	0 to 3000 psi
Accuracy	+/-2-1-2%
Material	Stainless Steel
Application	General Purpose
Gauge Primary Range Values	0 to 3000
Gauge Primary Range Units	psi
Gauge Connection Type	MNPT
Basic Gauge Case Material	Stainless Steel
Case Color	Metallic
Gauge Lens Material	Polycarbonate
Max. Pressure (PSI)	3000
Gauge Panel Mountable	No
Basic Gauge Wetted Parts	Copper
Gauge Primary Range Smallest Graduation	50
Gauge Case Material	Stainless Steel
Calibration Certificate Included	No
Basic Gauge Socket Material	Copper
Gauge Filled With	Glycerin
Series	201L
Operating Temp. Range	30 Degrees to 160 Degrees F
Gauge Primary Range Numbered Graduations	500
Smallest Graduation	50 psi
Gauge Socket Material	Copper Alloy
Graduations	500 psi
Gauge Connection Location	Bottom
Pressure and Vacuum Gauge Type	Pressure Gauge
Basic Gauge Sensor Material	Copper
Gauge Case Color	Stainless Steel
Liquid Filled	Yes
Gauge Accuracy	+/-2-1-2%
Gauge Sensor Material	Copper Alloy
Basic Gauge Lens Material	Plastic
Case Material	Stainless Steel
Socket Material	Copper Alloy
Pressure Range	0 to 3,000 psi
Process Connection	1/4 in NPT Male
Standards	ASME
Blowout Safety Back	No
Primary Scale Units	psi
Lens Material - Gauge	Plastic
Includes Mounting Hardware	No
Dry Dampening Feature	None
Process Connection Location	Bottom
Pointer Material	Aluminum
Accuracy Scale	Mid-Scale
Pressure Range Type	Pressure
Process Connection Type	NPT
Hazardous Location Rating	Not Rated
Primary Scale Minor Graduations	50
Primary Scale Numeric Increments	500
Bezel Mounting Type	Fixed
Dial Color	White
Ambient Operating Temperature Range	-30 Degrees to 180 Degrees F
Dial Face Color	White
Sensor Material	Copper Alloy
IP/NEMA Rating	Not Rated
Gauge Wetted Parts	Copper
Freeze Resistant Movement	No
Gauge Case Liquid	Glycerin
Field Fillable	No
Pointer Color	Black
Includes Vent Plug	Yes
Panel-Mountable	No
Primary Pressure Range	0 to 3,000
Secondary Scale Units	bar
Liquid-Filled Case	Yes
Process Temperature Range	30 Degrees to 160 Degrees F
Non-Sparking	No
Accuracy Grade	ASME B40.100 Grade A
Cleaned for Oxygen Service	No
Gauge Accuracy Grade	Grade A - Industrial
Pressure Gauge Type	Industrial Pressure Gauge
Scale Type	Dual
Lens Material	Polycarbonate
Secondary Pressure Range	0 to 207
Bezel Material	Stainless Steel
Vibration Resistance	Liquid-Filled
Includes Calibration Certificate	No
Process Connection Gender	Male
Removable Bezel	No
