| Connection Location |
Lower |
| For Use With |
Brass, Industrial Applications, Media Compatible with Copper Alloy |
| Gauge Application |
In Applications Where Vibration or Pulsation is Present |
| Range |
0 to 100 psi |
| Accuracy |
+/-2-1-2% |
| Material |
Stainless Steel |
| Application |
Industrial |
| Gauge Primary Range Values |
0 to 100 |
| Gauge Primary Range Units |
psi |
| Gauge Connection Type |
MNPT |
| Basic Gauge Case Material |
Stainless Steel |
| Case Color |
Metallic |
| Basic Gauge Socket Material |
Stainless Steel |
| Liquid Filled |
Yes |
| Basic Gauge Wetted Parts |
Stainless Steel |
| Graduations |
20 psi |
| Max. Pressure (PSI) |
100 |
| Gauge Filled With |
Glycerin |
| Gauge Special Options |
Heavy Duty |
| Basic Gauge Lens Material |
Plastic |
| Gauge Accuracy |
+/-2-1-2% |
| Calibration Certificate Included |
No |
| Gauge Primary Range Numbered Graduations |
20 |
| Gauge Primary Range Smallest Graduation |
2 |
| Basic Gauge Sensor Material |
Stainless Steel |
| Gauge Case Color |
Stainless Steel |
| Smallest Graduation |
2 psi |
| Operating Temp. Range |
30 Degrees to 160 Degrees F |
| Gauge Sensor Material |
316 Stainless Steel |
| Gauge Connection Location |
Bottom |
| Gauge Case Material |
Stainless Steel |
| Gauge Panel Mountable |
No |
| Gauge Lens Material |
Polycarbonate |
| Pressure and Vacuum Gauge Type |
Pressure Gauge |
| Series |
300 |
| Gauge Socket Material |
316 Stainless Steel |
| Socket Material |
316 Stainless Steel |
| Standards |
ASME |
| Scale Type |
Dual |
| Accuracy Scale |
Mid-Scale |
| Includes Calibration Certificate |
No |
| Primary Scale Minor Graduations |
2 |
| Process Connection Type |
NPT |
| Ambient Operating Temperature Range |
30 Degrees to 160 Degrees F |
| Dial Face Material |
Stainless Steel |
| Dial Color |
White |
| Vibration Resistance |
Liquid-Filled |
| Pointer Material |
Aluminum |
| Cleaned for Oxygen Service |
No |
| Includes Vent Plug |
No |
| Field Fillable |
No |
| Removable Bezel |
No |
| IP/NEMA Rating |
Not Rated |
| Process Connection Location |
Bottom |
| Pointer Color |
Black |
| Non-Sparking |
No |
| Blowout Safety Back |
No |
| Liquid-Filled Case |
Yes |
| Panel-Mountable |
No |
| Bezel Material |
Stainless Steel |
| Gauge Case Liquid |
Glycerin |
| Includes Mounting Hardware |
No |
| Pressure Gauge Type |
Industrial Pressure Gauge |
| Primary Scale Numeric Increments |
20 |
| Freeze Resistant Movement |
No |
| Secondary Pressure Range |
0 to 7 |
| Hazardous Location Rating |
Not Rated |
| Lens Material |
Polycarbonate |
| Primary Pressure Range |
0 to 100 |
| Sensor Material |
316 Stainless Steel |
| Primary Scale Units |
psi |
| Bezel Mounting Type |
Fixed |
| Dry Dampening Feature |
None |
| Secondary Scale Units |
bar |
| Accuracy Grade |
ASME B40.100 Grade A |
| Pressure Range Type |
Pressure |
| Process Connection Gender |
Male |
