Parker 4MTC8N-316 Thermocouple Connector 316 Stainless Steel, Compression x MNPT, For 1/4 in Tube OD

Thermocouple Connector, Application Gases, Liquids, Fitting Side A Connection Type Compression, Fitting Side B Connection Type MNPT, Fitting Material Stainless Steel, Fitting Side A Tube Outer Diameter 1/4 in, Material Grade 316, Maximum Operating Pressure 10,300 psi, Maximum Operating Temperature 1,200 Degrees F, Overall Length 1 7/8 in, Specific Fitting Shape Straight Thermocouple Adapter, Fitting Side B Pipe Size 1/2 in, Compatible Fitting Brands A-LOK, Thread Size A 7/16-20

Basic Pipe Fitting Material	Metal
Specific Fitting Shape	Straight Thermocouple Adapter
Standards	ASME SA-213, ASTM A213, ASTM A249, ASTM A269, MIL-T-8504, MIL-T-8506
Basic Pipe Fitting Shape	Connector
Temp. Range	-425 Degrees to 1200 Degrees F
Tube Fitting Material	Stainless Steel
Fitting Connection Type	A-LOK(R) x MNPT
Specific Pipe Fitting Shape	Connector
Max. Pressure	10,300 psi
Item	Thermocouple Connector
Pipe Fitting Connection Type	A-LOK(R) x MNPT
Maximum Operating Pressure	10,300 psi
Fitting Side B Connection Type	MNPT
Material Grade	316
Fitting Material	Stainless Steel
Fitting Side A Connection Type	Compression
Minimum Operating Temperature	425 Degrees F
Application	Gases, Liquids
System of Measurement	Imperial
Resistance Properties	Corrosion-Resistant, Gall-Resistant
Maximum Operating Temperature	1,200 Degrees F
Compatible Fitting Brands	A-LOK
Fitting Shape	Adapter
Connection Type	Compression x MNPT
For Tube OD	1/4 in
Fitting Body Material	316 Stainless Steel
End Connection Type	Compression, Threaded
