| Gas Detected |
Carbon Monoxide, Combustible Gas, Hydrogen Sulfide, Oxygen |
| Alarm Type |
Audible |
| Alarm Setting |
95 dB @ 1 ft (30 cm) |
| Battery Life |
1 day |
| Operating Temp. Range |
-10 Degrees to 40 Degrees C (-50 Degrees to 104 Degrees F) |
| Standards |
CAN/CSA C22.2 No. 152 Combustible Gas Detection Instruments C22.2 No. 152, CE 0080 Directive 2014/30/EU (EMC): EN50270 Type 2, EN61000-6-3, Directive 2014/34/EU (ATEX): II 1G Ex ia da IIC T4 Ga, Ex ia da IIC T4 Ga, IECEX, ISO 9001 |
| Sensor Range |
0 to 100% LEL, 0 to 1999 ppm CO, 0 to 200 ppm H2S, 0 to 30-% Vol O2 |
| Housing Color |
Gray |
| Features |
Sense Gas Twice Faster Than The Industry Average with Xcell Sensors, Survives 25 Drops From 4 ft (1-1/4m), MIL-STD-810G Drop Protection, 4 yr Instrument and Sensor Warranty, Motion Alert Option Tells Others That User Has Become Immobile, Bump and Calibrate with 1/2 The Test Gas and In 1/2 The Time Vs. Industry Average |
| Resolution |
1% LEL, Carbon Monoxide 1 ppm, Hydrogen Sulfide 1 ppm, Oxygen 0.1% vol |
| Includes |
Calibration Tubing, Power Supply |
| IP Rating |
IP68 |
| Chemical Formula |
CO, H2S, O2 |
| Power Source |
Battery |
| Display Screen Type |
LCD |
| Operating Humidity - Minimum |
5 % |
| Measurement Range |
0 to 100% LEL, 1, Carbon Monoxide (0 to 1,999 ppm), Hydrogen Sulfide (0 to 200 ppm) |
| Hazardous Location Specification |
Class I Divisions 1 Groups A, B, C, D, Class II Divisions 1 Groups E, F, G, Class III Divisions 1 |
| Replaceable Battery |
Yes |
| Rechargeable Battery |
Yes |
| Operating Temperature - Maximum |
140 Degrees F |
| Data Logger |
Yes |
| Series |
ALTAIR 4XR |
| Operating Temperature - Minimum |
-40 Degrees F |
| Communication Protocol |
Bluetooth |
| Number of Gases Detected |
4 |
| Operating Humidity - Maximum |
95 % |
| Sensor Life |
4 yr |
| Battery Chemistry |
Lithium Ion Polymer |
| Temperature Code |
T4 |
| Display Type |
Digital |
| Includes Probe |
No |
| Alert Type |
Sound |
