| Connection Type |
Flanged |
| Connection |
Flanged |
| Body Material |
Cast Steel |
| Sub-Category |
Steel |
| Max. Temp. |
1000 Degrees F @ 20 psi |
| Mounting Position |
Horizontal |
| Body Material - Valves |
Cast Steel |
| Standards |
API 600 ASME B 16.34 |
| Material of Construction |
Cast Steel |
| Max. Water Pressure |
285 psi @ 100 Degrees F |
| Seal Material - Check Valves |
Chrome, Cobalt |
| Item - Check Valves |
Check Valve |
| Seat Material |
Cobalt/Chrome |
| Connection Type - Check Valves |
Flange x Flange |
| Application - Valves |
General Purpose |
| Max. Temp. - Valves |
1,000 Degrees F |
| Cracking Pressure |
2 psi |
| Full Flow - Valves |
Yes |
| Item |
Swing Check Valve |
| Flow - Valves |
327 gpm |
| Cap to Inlet Center |
7 3/32 in |
| Mounting Orientation - Check Valves |
Horizontal |
| Max. Water Pressure - Valves |
285 psi @ 100 Degrees F |
| Mechanism and Body Design |
Inline Swing |
| Max. Steam Pressure - Valves |
200 psi WSP |
| Min. Temp. - Valves |
-20 Degrees F |
| Cracking Pressure - Check Valves |
2.0 psi |
| Flow Design |
Single |
| Seat Material - Check Valves |
Chrome, Cobalt |
| Max. Pressure |
285 psi @ 100 Degrees F |
| Flow |
327 gpm |
| Seal Material |
Cobalt Chrome Alloy |
| Mounting Orientation |
Horizontal |
| Valve Body Style |
Inline |
| 3-A Standard Compliance |
Not Rated |
| Connection Type - Side 1 |
Flange |
| Connection Type - Side 2 |
Flange |
| Silent Check |
Standard |
| Maximum Pressure - Steam |
200 psi |
| ANSI Flange Class |
Class 150 |
| Check Mechanism |
Swing |
| Maximum Pressure - Operating |
285 psi |
| Operating Temperature - Maximum |
1,000 Degrees F |
| Coefficient of Volume (Cv) |
282 |
| For Media |
Steam, Water |
| Check Mechanism Material |
Steel |
| Vacuum Service Rating |
Not Rated |
| Operating Temperature - Minimum |
-20 Degrees F |
| Includes Counterweight |
No Counterweight |
| Valve Series |
1570CB2 |
