| Welding Processes |
Stick Welding (SMAW), TIG Welding (GTAW) |
| Input Voltage |
110/115/120V AC, 208V AC, 220/230/240V AC, 380/400V AC, 460/480V AC |
| Rated Output |
210A @ 18V |
| Welder Max. Output Amps |
210 |
| Welder Min. Output Amps |
1 |
| Welder Duty Cycle |
60 % |
| Series |
Maxstar 210 STR |
| Welded Material |
Mild Steel, Stainless Steel |
| Features |
Digital Meters, Dual Memory Selections, Fan-On-Demand, Hot Start, Operator Friendly Interface, Pro-Set |
| Welder Input Hz |
50/60 |
| Includes |
Power Source Only |
| Polarity |
DC |
| Application |
Aerospace, Dairy, Food and Beverage Industry, Petro Chemical, Precision Fabrication, Shipboard |
| Input (Amps) |
26/6 |
| Welder Input Phase |
1 or 3 |
| Power Source Weight |
38 lb |
| Standards |
CSA |
| Phase |
Single-/Three-Phase |
| TIG Arc Start Feature |
Lift Arc Start |
| TIG Welding Minimum Output Current |
5 A |
| TIG Welding Maximum Output Current |
210 A |
| Input Frequency |
50/60 Hz |
| For Material Type |
Stainless Steel, Steel |
| Plug Type |
Bare Leads |
| Stick Welding Output @ Duty Cycle |
160 A @ 26.4 V, 60% (3-Phase), 90 A @ 23.6 V, 60% (1-Phase) |
| Remote Connection Type |
14-Pin (Miller) |
| TIG Welding Output @ Duty Cycle |
125 A @ 15 V, 60% (1-Phase), 210 A @ 18 V, 60% (3-Phase) |
| Color |
Blue |
| Stick Welding Maximum Output Current |
210 A |
| Weight |
38 lb |
| Welding Mode |
CC |
| Open Circuit Voltage |
80 V DC |
| Cable Connection Type |
Dinse-Style |
| Stick Welding Minimum Output Current |
5 A |
| Effective Input Current |
10 A @ 480V AC (Single-Phase), 11 A @ 480V AC (Single-Phase), 12 A @ 240V AC (Three-Phase), 12 A @ 400V AC (Single-Phase), 13 A @ 240V AC (Three-Phase), 13 A @ 400V AC (Single-Phase), 14 A @ 208V AC (Three-Phase), 15 A @ 208V AC (Three-Phase), 20 A @ 240V AC (Single-Phase), 22 A @ 120V AC (Single-Phase), 22 A @ 240V AC (Single-Phase), 23 A @ 120V AC (Single-Phase), 24 A @ 208V AC (Single-Phase), 26 A @ 208V AC (Single-Phase), 6 A @ 480V AC (Three-Phase), 7 A @ 400V AC (Three-Phase), 8 A @ 400V AC (Three-Phase) |
|
|
