| Welder Industrial Class |
Medium |
| Welding Processes |
Stick Welding (SMAW), TIG Welding (GTAW) |
| Input Voltage |
110/115/120V AC, 208V AC, 220/230/240V AC, 380/400V AC, 460/480V AC |
| Rated Output |
210A @ 18V |
| Welder Max. Output Amps |
210 |
| Welder Min. Output Amps |
1 |
| Welder Duty Cycle |
60 % |
| Series |
Maxstar 210 DX |
| Welded Material |
Mild Steel, Stainless Steel |
| Power Source Weight |
38 lb |
| Input (Amps) |
26/6 |
| Application |
Aerospace, Dairy, Food and Beverage Industry, Petro Chemical, Precision Fabrication, Shipboard |
| Polarity |
DC |
| Welder Input Hz |
50/60 |
| Welder Input Phase |
1 or 3 |
| Features |
Wireless Remote Compatible |
| Includes |
Power Source Only |
| Phase |
Single-/Three-Phase |
| Standards |
CE, CSA, ISO |
| Open Circuit Voltage |
80V DC |
| Max. Input Current |
15 A @ 208V (Three-Phase), 26 A @ 208V (Single-Phase) |
| TIG Welding Output @ Duty Cycle |
210 A @ 18.4 V, 60%, 125 A @ 15 V, 60% |
| Power Cord Included |
Yes |
| Welding Mode |
CC |
| Stick Welding Output @ Duty Cycle |
160 A @ 26.4 V, 60%, 90 A @ 23.6 V, 60% |
| Input Frequency |
50/60 Hz |
| Stick Welding Maximum Output Current |
210 A |
| Pulse Frequency |
0.1 to 500 pulses/second |
| Remote Control |
Remote Control Not Included |
| For Material Type |
Specialty Metals, Stainless Steel, Steel |
| TIG Welding Minimum Output Current |
1 A |
| Weight |
38 lb |
| TIG Arc Start Feature |
High Frequency Start, Lift Arc Start |
| Amperage Range |
1 to 210 A |
| TIG Welding Maximum Output Current |
210 A |
| Remote Connection Type |
14-Pin (Miller) |
| Plug Type |
Bare Leads |
| Stick Welding Minimum Output Current |
5 A |
| Color |
Blue |
| Model |
907684 |
