Fuse, 3 1/2 A, 600 V AC, 600 V DC, Class CC, ATMR Series, Non-Indicating, Fast-Acting, Body Style Cylindrical, Fits Fuse Block Style Rejection, Interrupt Rating 100kA at 600V DC, 200kA at 600V AC, Fuse Size 1-1/2 in L x 13/32 in dia, Length 1 1/2 in, Diameter 13/32 in, Equivalent Brand and Series Bussmann KTK-R, Littelfuse KLKR, Mersen ATMR, Equivalent Series ATMR, KLKR, KTK-R, Compatible Fuse Block Series USCC, USFMCC, Body Material Melamine, Single Element, Standards UL/CSA
| Class |
CC |
| Series |
ATMR |
| Speed |
Fast-Acting |
| Amps |
3.5A |
| AC Voltage Rating |
600V AC |
| DC Voltage Rating |
600V DC |
| Visual Indication |
Non-Indicating |
| Interrupt Rating |
100kA at 600V DC, 200kA at 600V AC |
| Body Style |
Cylindrical |
| Body Material |
GMG |
| Equivalent Brand and Series |
Bussmann KTK-R, Littelfuse KLKR, Mersen ATMR |
| Equivalent Series |
ATMR, KLKR, KTK-R |
| Fits Fuse Block Style |
Rejection |
| Compatible Fuse Block Series |
USCC, USFMCC |
| Rejection / Nonrejection |
Rejection |
| Mounting |
Clip |
| Connection Material |
Tin-Plated Copper |
| Standards |
UL/CSA |
| Weight |
0.02 lb |
| Element |
Single |
| Green Environmental Attribute |
RoHS 2011/65/EU Compliant |
| AC Max I.R./Breaking Capacity: I1 |
200 kA |
| Connection/Terminal Material |
Tin-Plated Copper |
| Frequency |
50/60 Hz |
| Fuse Speed |
Fast Acting |
| Fuse Holder Code |
D/W |
| In Line Fuseholder |
D/W |
| Current |
3.5 A |
| Interrupt Rating - DC |
100 kA |
| Interrupt Rating - AC |
200 kA |
| Country of Origin |
Mexico |
