| Retaining Ring Type |
External |
| Material |
15-7 PH Stainless Steel |
| Number of Pieces |
218 |
| Includes |
For 1/4" to 3" OD |
| Features |
Compartmented, Lid Chart |
| Type |
Plastic Box |
| Depth |
1 3/4" |
| Length |
10 3/4" |
| Width |
6 1/2" |
| External Retaining Rings Included |
For 1 1/2" OD (5 Pieces), For 1 1/4" OD (10 Pieces), For 1 3/4" OD (5 Pieces), For 1 3/8" OD (10 Pieces), For 1 5/8" OD (5 Pieces), For 1" OD (20 Pieces), For 1 1/8" OD (10 Pieces), For 1 5/16" OD (5 Pieces), For 1/2" OD (20 Pieces), For 1/4" OD (20 Pieces), For 2 1/2" OD (2 Pieces), For 2 1/4" OD (2 Pieces), For 2 5/8" OD (2 Pieces), For 2" OD (5 Pieces), For 3" OD (2 Pieces), For 3/4" OD (20 Pieces), For 3/8" OD (20 Pieces), For 5/8" OD (20 Pieces), For 7/8" OD (10 Pieces), For 5/16" OD (10 Pieces), For 7/16" OD (5 Pieces), For 9/16" OD (5 Pieces), For 13/16" OD (5 Pieces) |
| For OD |
1/4", 5/16", 3/8", 7/16", 1/2", 9/16", 5/8", 3/4", 13/16", 7/8", 1", 1 1/8", 1 1/4", 1 5/16", 1 3/8", 1 1/2", 1 5/8", 1 3/4", 2", 2 1/4", 2 1/2", 2 5/8", 3" |
| For Shaft Bore Type |
With Retaining Ring Grooves |
| For Shaft End Type |
Retaining Ring Groove |
| Performance |
Corrosion Resistant |
| Retaining Ring Style |
Tapered |
| System of Measurement |
Inch |
| Country of Origin |
United States |
| DFARS Compliance |
Specialty Metals COTS-Exempt |
| Export Control Classification Number (ECCN) |
EAR99 |
| REACH Compliance |
REACH (EC 1907/2006) (02/04/2026, 253 SVHC) Compliant |
| RoHS Compliance |
RoHS 3 (2015/863/EU) Compliant |
| Schedule B Number |
392690.9988 |
| U.S.–Mexico–Canada Agreement (USMCA) Qualifying |
Yes |
