McMaster 4844N51 T-Slotted Framing Structural Bracket, Black Gusset Bracket for 40mm Double/Quad Rail, 1.58" Long

McMaster 4844N51 T-Slotted Framing Structural Bracket, Black Gusset Bracket for 40mm Double/Quad Rail, 1.58" Long

Name: McMaster 4844N51 T-Slotted Framing Structural Bracket, Black Gusset Bracket for 40mm Double/Quad Rail, 1.58" Long
Brand: McMaster-Carr
Price: 69.33 USD
Availability: InStock

UPC: | Harmonization / Schedule B : 7616.99.5195

Country of Origin: China | Shipping Weight: 1.0 lbs

$69.33 - $69.33

$69.33

$69.33 - $69.33

$69.33

Connect T-slotted rails for structural stability. Fasteners are included.

Open Gusset — Reinforced to limit sway for more structural stability than standard corner brackets. Their sides are open, giving easy access to fasteners that you need to adjust frequently.

Bracket Type	Corner
T-Slotted Framing Bracket Type	Standard
Gusset Bracket Type	Open
Corner Bracket Type	Gusset
For T-Slotted Framing Rail Profile	Double Quad
Color	Black
Height	40 mm
Length	1 37/64"
Material	Anodized Aluminum
Rail Machining Required	No
Type	Screw and Nut Set
Installation Type	Drop In
Head Style	Button
Thread Size	M8
Thread Length	16 mm
Color	Silver
Included	Yes
Number Included	4
For Rail Connection Angle	90°
Framing Type	T-Slotted
Material Grade	6063 Aluminum
Shape	90° Angle
System of Measurement	Metric
T-Slotted Framing Component	Bracket
Temper Designation	T5
Country of Origin	China
DFARS Compliance	Specialty Metals COTS-Exempt
Export Control Classification Number (ECCN)	EAR99
REACH Compliance	REACH (EC 1907/2006) (06/25/2025, 250 SVHC) Compliant
RoHS Compliance	RoHS 3 (2015/863/EU) Compliant
Schedule B Number	761699.5195
U.S.–Mexico–Canada Agreement (USMCA) Qualifying	No
