McMaster 44705K922 Low-Pressure 6061 Aluminum Pipe Adapter, 1-1/4 NPT Female x Butt-Weld, Class 150 (sub for 44705K322 — NOT MIL-DTL-52618 certified)

McMaster 44705K922 Low-Pressure 6061 Aluminum Pipe Adapter, 1-1/4 NPT Female x Butt-Weld, Class 150 (sub for 44705K322 — NOT MIL-DTL-52618 certified)

UPC: | Harmonization / Schedule B : 7609.00.0000

Country of Origin: United States | Shipping Weight: 1 lbs

$49.35 - $49.35
$49.35
$49.35 - $49.35
$49.35

In addition to being lightweight, these aluminum fittings offer good corrosion resistance. Use them in low-pressure flow applications. To prevent cracking, do not tighten more than a 1/4-turn past hand tight.

Threaded Fitting Connection — Threaded female x butt weld straight adapters are also known as half couplings.

Note: This is McMaster's suggested substitute for 44705K322 (discontinued). 44705K922 is 31/32" long vs 1" on K322, and does NOT meet MIL-DTL-52618.

Pressure Rating Low Pressure
Shape Straight
Fitting Type Adapter
Fitting Connection NPT Female × Butt Weld
Pipe Size A 1 1/4"
Pipe Size B 1 1/4"
Pressure Class 150
Material 6061 Aluminum
Maximum Pressure @ Temperature 150 psi @ 72°F
Length 31/32"
Wall Thickness 0.234"
Threading Threaded on One End
Construction (B) Welded
For Pipe Schedule 40
For Use With Air, Oil, Water
Performance Corrosion Resistant
Specifications Met ASME B1.20.1, ASTM A865, ASTM B221
System of Measurement Inch
Country of Origin United States
DFARS Compliance Specialty Metals COTS-Exempt
ECCN EAR99
REACH Compliance REACH (EC 1907/2006) (02/04/2026, 253 SVHC) Compliant
RoHS Compliance RoHS 3 (2015/863/EU) Compliant
Schedule B Number 7609.00.0000
USMCA Qualifying Yes
