Loctite 135486 Pipe Thread Sealant, 545, 1.7 fl oz, Bottle, Purple

Loctite 135486 Pipe Thread Sealant, 545, 1.7 fl oz, Bottle, Purple

UPC: 079340545311 | Harmonization / Schedule B : 3506.10.5000

Country of Origin: United States | Shipping Weight: 0.15 lbs

$79.29 - $79.29
$79.29
$79.29 - $79.29
$79.29

Pipe Thread Sealant, Cure Type Anaerobic, Series 545, Container Size 1.7 fl oz, Container Type Bottle, Maximum Operating Temperature 300 Degrees F, Minimum Operating Temperature -65 Degrees F, Maximum Operating Pressure for Liquids 10,000 psi, Color Purple, For Material Type Metal, Specific Sealing Application For Hydraulic Systems, Standards ISO 10964, For Maximum Thread Diameter 3/4 in, Application Method Brush, Chemical Base Methyl Methacrylate, Clean Up Method Loctite Solvent

Container Size 1.7 fl oz
Size 50 mL
For Maximum Thread Diameter 3/4 in
MFR # 135486
Zoro # G3485361
UPC # 079340545311
Country of Origin United States
Container Type Bottle
Color Purple
Chemical Base Methyl Methacrylate
Series 545
Product Form Liquid
Resistance Properties Pressure Resistant
Begins to Harden Not Specified
Viscosity 14,000cP
For Use With Primer 7088, 7649, or 7471
Chemical Type Methacrylate Ester
Flash Point 200 Degrees F
Application Temp. Range 72 Degrees F
Includes Pneumatic and Hydraulic Fittings
Specific Gravity 1.02
Application Locks and Seals Hydraulic and Pneumatic Fittings without Fouling the System, Suitable for Fittings Up to 50mm in Diameter
Performance Temp. Range -65 Degrees to 300 Degrees F
Gas Pressure Range 10,000 psi
For Material Type Metal
Standards ISO 10964
Full Cure Time 1 day
Maximum Operating Pressure for Liquids 10,000 psi
Application Method Brush
For Thread Type Fine Threads
Shear Strength 220 psi
Mixing Required No
Minimum Viscosity 9,000 cps
Maximum Viscosity 20,000 cps
Maximum Operating Temperature 300 Degrees F
Clean Up Method Loctite Solvent
Minimum Operating Temperature -65 Degrees F
Specific Sealing Application For Hydraulic Systems
Compatible Primer Series 7088, 7471, 7649
Storage Requirements 8 Degrees to 21 Degrees C
VOC Content 19.01 g/L
Maximum Application Temperature 72 Degrees F
Cure Type Anaerobic
Characteristics Lubricity High Lubricity,No Fillers/Particles,Solvent Resistant,Viscosity Medium Viscosity
Country of Origin USA (subject to change)
