Littelfuse FLSR015 Fuse, Class RK5, FLSR Series, Time-Delay, 15 A, 600 V AC, 300 V DC, Non-Indicating

Littelfuse FLSR015 Fuse, Class RK5, FLSR Series, Time-Delay, 15 A, 600 V AC, 300 V DC, Non-Indicating

UPC: 079458170689 | Harmonization / Schedule B : 8536.10.0040

Country of Origin: Mexico | Shipping Weight: 0.18 lbs

$22.44 - $22.44
$22.44
$22.44 - $22.44
$22.44

Fuse, 15 A, 600 V AC, 300 V DC, Class RK5, FLSR Series, Non-Indicating, Time-Delay, Body Style Cylindrical, Fits Fuse Block Style Rejection, Interrupt Rating 200kA at 600V AC, 20kA at 300V DC, Fuse Size 5 in L x 13/16 in dia, Length 5 in, Diameter 13/16 in, Equivalent Brand and Series Bussmann FRS-R, Edison ECSR, Littelfuse FLSR, Mersen TRS-R, Equivalent Series ECSR, FLSR, FRS-R, TRS-R, Compatible Fuse Block Series LFR, Body Material Fiberglass, Dual Element

CAD Available Yes
Class RK5
Series FLSR
Speed Time-Delay
Amps 15A
AC Voltage Rating 600V AC
DC Voltage Rating 300V DC
Visual Indication Non-Indicating
Interrupt Rating 200kA at 600V AC, 20kA at 300V DC
Body Style Cylindrical
Body Material Fiberglass
Equivalent Brand and Series Bussmann FRS-R, Edison ECSR, Littelfuse FLSR, Mersen TRS-R
Equivalent Series ECSR, FLSR, FRS-R, TRS-R
Fits Fuse Block Style Rejection
Compatible Fuse Block Series LFR
Element Dual
Standards CE, CSA Certification, QPL-W-F-1814, UL 248-12 Class RK5
Functionally Equal To Bussmann FRS-R, Edison ECSR, Mersen/Ferraz Shawmut TRS-R
Opening Slo-Blo/Time Lag (T)/Time Delay
Current 15 A
Interrupt Rating - DC 20 kA
Interrupt Rating - AC 200 kA
Country of Origin Mexico
