| For Use With |
Air, Water, and Oils in Hydraulic Equipment, Pressure Washers, Pumps, and Compressors |
| Gauge Application |
Corrosion-Resistant Case |
| Range |
0 to 1400 kPa, 0 to 200 psi |
| Accuracy |
+/-3-2-3% |
| Material |
304 Stainless steel |
| Color |
Stainless Steel |
| Application |
Test and Measurement |
| Gauge Primary Range Values |
0 to 200 |
| Gauge Primary Range Units |
psi |
| Gauge Connection Type |
MNPT |
| Basic Gauge Case Material |
Stainless Steel |
| Case Color |
Silver |
| Gauge Primary Range Smallest Graduation |
5 |
| Gauge Secondary Range Units |
kPa |
| Basic Gauge Sensor Material |
Stainless Steel |
| Gauge Connection Location |
Center Back |
| Operating Temp. Range |
-40 Degrees to 150 Degrees F |
| Basic Gauge Socket Material |
Stainless Steel |
| Smallest Graduation |
5 psi |
| Basic Gauge Lens Material |
Plastic |
| Gauge Sensor Material |
316 Stainless Steel |
| Gauge Accuracy |
+/-3-2-3% |
| Gauge Lens Material |
Acrylic |
| Liquid Filled |
No |
| Gauge Secondary Range Values |
0 to 1400 |
| Gauge Panel Mountable |
No |
| Gauge Case Material |
304 Stainless Steel |
| Gauge Case Color |
Stainless Steel |
| Pressure and Vacuum Gauge Type |
Pressure Gauge |
| Calibration Certificate Included |
No |
| Max. Pressure (PSI) |
200 |
| Gauge Socket Material |
316 Stainless Steel |
| Basic Gauge Wetted Parts |
Stainless Steel |
| Socket Material |
316 Stainless Steel |
| Liquid-Filled Case |
No |
| Primary Pressure Range |
0 to 200 |
| Removable Bezel |
No |
| Includes Calibration Certificate |
No |
| Primary Scale Units |
psi |
| Bezel Material |
Crimped Stainless Steel |
| Hazardous Location Rating |
Not Rated |
| Cleaned for Oxygen Service |
No |
| Pressure Gauge Type |
General Purpose Dial Pressure Gauge |
| Field Fillable |
No |
| Secondary Pressure Range |
0 to 1,400 |
| Non-Sparking |
No |
| Freeze Resistant Movement |
No |
| Gauge Case Liquid |
None |
| Includes Mounting Hardware |
No |
| Panel-Mountable |
No |
| Accuracy Scale |
Mid-Scale |
| Ambient Operating Temperature Range |
-40 Degrees to 150 Degrees F |
| Process Connection Location |
Center Back |
| Sensor Material |
316 Stainless Steel |
| Pressure Range Type |
Pressure |
| Scale Type |
Dual |
| Lens Material |
Acrylic |
| Dial Color |
White |
| Blowout Safety Back |
No |
| Vibration Resistance |
None |
| Secondary Scale Units |
kPa |
| IP/NEMA Rating |
Not Rated |
| Dry Dampening Feature |
None |
| Process Connection Type |
NPT |
| Includes Vent Plug |
No |
| Primary Scale Minor Graduations |
5 |
| Process Connection Gender |
Male |
