| Accuracy |
+/-3-2-3% |
| Process Connection Location |
Center Back |
| Process Connection Type |
NPT |
| Application |
General Purpose |
| Gauge Case Material |
304 Stainless Steel |
| Lens Material |
Acrylic |
| Primary Pressure Range |
0 to 200 |
| Primary Scale Units |
psi |
| IP/NEMA Rating |
Not Rated |
| Liquid-Filled Case |
Yes |
| Hazardous Location Rating |
Not Rated |
| Panel-Mountable |
No |
| Blowout Safety Back |
No |
| Gauge Application |
Corrosion-Resistant Case |
| Gauge Secondary Range Values |
0 to 1400 |
| Smallest Graduation |
5 psi |
| Calibration Certificate Included |
No |
| Case Color |
Silver |
| Gauge Primary Range Smallest Graduation |
5 |
| Gauge Filled With |
Glycerin |
| For Use With |
Air, Water, and Oils in Hydraulic Equipment, Pressure Washers, Pumps, and Compressors |
| Socket Material |
316 Stainless Steel |
| Case Material |
304 Stainless Steel |
| Connection Type |
MNPT |
| Wetted Materials |
Stainless Steel |
| Pressure Range Type |
Pressure |
| Process Connection Gender |
Male |
| Includes Calibration Certificate |
No |
| Dial Color |
White |
| Ambient Operating Temperature Range |
-40 Degrees to 140 Degrees F |
| Secondary Pressure Range |
0 to 1,400 kPa |
| Includes Mounting Hardware |
No |
| Freeze Resistant Movement |
No |
| Vibration Resistance |
Liquid-Filled |
| Accuracy Scale |
Mid-Scale |
| Bezel Material |
Crimped Stainless Steel |
| Pressure Gauge Type |
Commercial Pressure Gauge |
| Sensor Material |
316 Stainless Steel |
| Cleaned for Oxygen Service |
No |
| Non-Sparking |
No |
| Removable Bezel |
No |
| Primary Scale Minor Graduations |
1, 2 |
| Includes Vent Plug |
No |
| Gauge Case Liquid |
Glycerin |
| Secondary Scale Units |
kPa |
| Scale Type |
Dual |
| Field Fillable |
No |
| Dry Dampening Feature |
None |
| Maximum Pressure |
200 |
| Operating Temperature Range |
-40 Degrees to 140 Degrees F |
| Case Liquid |
Glycerin |
| Operating Temperature - Minimum |
-40 Degrees F |
| Primary Scale Pressure Measurement - Minimum |
0 psi |
| Secondary Scale Pressure Measurement - Minimum |
0 kPa |
| Operating Temperature - Maximum |
140 Degrees F |
| Secondary Scale Pressure Measurement - Maximum |
1,400 kPa |
| Primary Scale Pressure Measurement - Maximum |
200 psi |
