| Voltage |
120V AC |
| Amps |
40 A |
| Enclosure Type |
Steel |
| Min. Time Setting |
1 hr |
| Max. Time Setting |
23 hr |
| Contact Form |
SPST |
| Max. On/Off Cycles |
12 |
| Extra Trippers |
2E054 |
| Description/Special Features |
3R Enclosures in Steel or Noncorrosive Plastic, Has Adjustable Time Setting, Manual On/Off Override does not Alter Program, Snap-out Timing Mechanism, Up to 12 On/Off Settings Per Day |
| Time Setting Range |
1 hr. to 23 hr. |
| Day Skipper |
No |
| Nominal Max. Time Setting |
24 hr |
| Contact HP @ 120V |
2 hp |
| Contact HP @ 240V |
5 hp |
| NEMA Rating |
3R |
| Type |
24-Hour |
| Number of Poles |
1 |
| Number of Trippers Included |
2 |
| Mount |
Hole Wall |
| Finish |
Metal Enclosure has Gray Enamel |
| Standards |
cCSAus, cULus |
| Product Type |
Timer |
| Operation Mode |
24 hour |
| Electronic Ballast Load Ratings Ranges |
16 A, 120 VAC |
| Application Compatibilities |
LED; HID |
| Packaging Applications |
Indoor/Outdoor Lighting; Signs; Filters; Electric Fences; Fans; Conveyors; Pool Heaters; Blowers; Pumps |
| Has Manual Override CVL |
Yes |
| Operating Temperature Min |
-40°C |
| Power Consumption Max W |
3 W |
| Minimum On Off Time |
1 hour |
| UL Certification |
cULus |
| Market |
Commercial; Industrial |
| Inductive Load Ratings |
40 A, 240 VAC, 60 Hz; 40 A, 208 VAC, 60 Hz; 40 A, 120 VAC, 60 Hz |
| Solutions |
Machinery & Pumps; Panel Integrators |
| Motor Load Ratings |
2 HP, 24 FLA @ 120 VAC, 60 Hz; 5 HP, 28 FLA @ 240 VAC, 60 Hz |
| Skipper Wheel Operation Mode |
Not Included |
| Maximum On Off Operations |
12 |
| Electronic Ballast Load Ratings |
16 A, 120 VAC |
| Operating Temperature Max |
130°C |
| Input Voltage Ranges |
120 VAC, 60 Hz |
| Tungsten Load Ratings Ranges |
40 A, 120-240 VAC, 60 Hz |
| Pilot Duty Load Ratings |
1000 VA, 120-240 VAC, 60 Hz |
| CSA Certification |
cCSAus |
| Inductive Load Ratings Ranges |
40 A, 120-240 VAC, 60 Hz |
| Tungsten Load Ratings |
40 A, 120 VAC, 60 Hz; 40 A, 208 VAC, 60 Hz; 40 A, 240 VAC, 60 Hz |
| UL Cerfication File Number |
UL917 |
| Wiring Option |
Terminals |
| Switch Type |
SPST |
| Resistive Load Ratings Ranges |
40 A, 120-240 VAC, 60 Hz |
| Number Of Circuits |
1 |
| Applications |
Timing/Scheduling ON/OFF; Indoor Lighting Control; Outdoor Lighting Control |
| Resistive Load Ratings |
40 A, 240 VAC, 60 Hz; 40 A, 208 VAC, 60 Hz; 40 A, 120 VAC, 60 Hz |
| Pilot Duty Load Ratings Ranges |
1000 VA, 120-240 VAC, 60 Hz |
| Maximum ON/OFF Operations |
12 |
| Operating Temperature Max (°F) |
130 |
| Has Manual Override |
Yes |
| Tungsten Range(s) |
40 A, 120-240 VAC, 60 Hz |
| Operating Temperature Min (°F) |
-40 |
| Inductive |
40 A, 120 VAC, 60 Hz, 40 A, 208 VAC, 60 Hz, 40 A, 240 VAC, 60 Hz |
| Input Voltage Range(s) |
120 VAC, 60 Hz |
| Features |
Manual Override |
| Skipper Wheel |
Not Included |
| Electronic Ballast |
16 A, 120 VAC |
| Tungsten (NO) |
40 A, 120 VAC, 60 Hz, 40 A, 208 VAC, 60 Hz, 40 A, 240 VAC, 60 Hz |
| Resistive |
40 A, 120 VAC, 60 Hz, 40 A, 208 VAC, 60 Hz, 40 A, 240 VAC, 60 Hz |
| Pilot Duty (NO) |
1000 VA, 120-240 VAC, 60 Hz |
| Motor Load Ratings Ranges |
2 HP, 24 FLA @ 120 VAC, 60 Hz; 5 HP, 28 FLA @ 240 VAC, 60 Hz |
| Minimum ON/OFF Times |
1 hour |
| Maximum Power Consumption (W) |
3 W |
| Operating Temperature Max (°F) |
130 |
| Operating Temperature Min (°F) |
-40 |
| Operating Temperature - Maximum |
130 Degrees F |
| Mounting Style |
Surface |
| Compatible Lighting |
HID, LED |
| AC Voltage Rating |
120V AC |
| Number of Trippers - Maximum |
2 |
| Series |
T100 |
| Operating Temperature - Minimum |
-40 Degrees F |
| On/Off Cycles - Maximum |
12 |
| Body Color |
Gray |
| Current Rating - Maximum |
40 A |
| Horsepower @ 240V - Maximum |
5 hp |
| Body Material |
Metal |
| Time Setting - Maximum |
24 hr |
| NEMA Enclosure Rating |
3R |
| Application |
Lighting |
| Time Setting - Minimum |
1 hr |
| Indoor/Outdoor Usage |
Indoor, Outdoor |
| Horsepower @ 120V - Maximum |
2 hp |
