| Gas Detected |
Carbon Monoxide, Chlorine, Hydrogen Sulfide, LEL, Oxygen |
| Alarm Type |
Audible, Vibrating, Visual |
| Alarm Setting |
1 ppm Danger, 20 ppm Danger, 20% Danger, 70 ppm Danger, Carbon Monoxide 35 ppm Warning, Chlorine 0.5 ppm Warning, Hydrogen Sulfide 10 ppm Warning, LEL 10%, Oxygen (High 23.5%, Low 19.5%) |
| Battery Life |
36 hr |
| Operating Temp. Range |
-4 Degrees to 131 Degrees F (-20 Degrees to 55 Degrees C) |
| Standards |
ANZEx: Ex ia s Zone 0 I, Ex ia s Zone 0 IIC T4, ATEX: Ex ia I, ATEX: Ex ia IIC T4 Ga, Cl II, Groups F G, Cl l Zone LEL 0, AEx ia d IIC T4 (or AEx ia d IIC T4 IR Sensor), CMA: Approval for Mining Products, CH4,O2,CO,CO2, CSA: Cl I, Gr A-D T4, EAC: PBExiadI X, 1ExiadIICT4 X, Equipment Group and Category: I M1/II 1G, Ex d ia IIC T4, Ex d ia IIC T4 Gb, Ex ia IIC T4 Ga, IECEX: Ex ia I (Ex ia d I IR Sensor), II 1G (or Ex d ia IIC T4 Gb IR Sensor), INMETRO: Ex ia IIC T4 Ga, KC: Ex d ia IIC T4, KIMM: Ex d ia IIC T4, MDR: Registration of Plant Design, CH4,O2,CO,H2S,NO2, MSHA: 30 CRF, Part 22, Intrinsically Safe for Methane/Air Mixtures, PA-DEP: BFE 114-08 Permissible for PA Bituminous Underground Mines, UL Class I Division 1, Groups A, B, C, D, T4 |
| Sensor Range |
CI2 0 to 100 ppm, CO 0 to 1500 ppm, H2S 0 to 500 ppm, LEL 0 to 100%, O2 0 to 30.0% |
| IP Rating |
IP64 |
| Series |
Ventis MX4 |
| Display Screen Type |
LCD |
| Chemical Formula |
CO, H2S |
| Includes |
Belt Clip, Calibration Cup (Diffusion), Calibration Tubing, Dust Filter/Water Stop (Aspirated), Nylon Carrying Case, Sample Tubing (Aspirated), Screwdriver, Wrist Strap |
| Housing Color |
Black |
| Features |
Prescreen Entries for Benzene with an Optional Convertible Kit, 24 Sensor Options: Including Photoionization Detectors and Infrared (IR) |
| Resolution |
Carbon Monoxide 1% vol, Hydrogen Sulfide 0.1% vol, Oxygen 0.1% vol, Sulfur Dioxide 0.1% |
| Power Source |
Battery |
| Hazardous Location Specification |
Class I Divisions 1 |
| Display Type |
Digital |
| Operating Temperature - Maximum |
131 Degrees F |
| Operating Temperature - Minimum |
-4 Degrees F |
| Includes Mounting Hardware |
Yes |
| Accuracy |
+/-0.5^5% (At Temperature of Calibration), +/-0.8^5% (Over Full Measurement Temperature), +/-15% (Over Full Measurement Temperature), +/-5% (0.0 to 200.0 ppm) +/-15% (200.1 to 500.0 ppm) (At Temperature of Calibration), +/-5% (At Temperature of Calibration) |
| Rechargeable Battery |
No |
| Measurement Range |
Carbon Monoxide (0 to 1500 ppm), Cl2 (0 to 50 ppm), Hydrogen Sulfide (0 to 500 ppm), Oxygen (0 to 30% vol) |
| Alert Type |
Light, Sound, Vibration |
| Number of Gases Detected |
4 |
| Operating Humidity - Minimum |
15 % |
| Data Logger |
Yes |
| Includes Probe |
No |
| Includes Charger |
Yes |
| Number of Sensors |
2 |
| Housing Material |
Stainless Steel |
| Battery Chemistry |
Lithium Ion |
| Temperature Code |
T4 |
| Operating Humidity - Maximum |
95 % |
| Replaceable Battery |
Yes |
| Alarm Volume Level |
95 dB |
| Sensor Type |
Infrared, Photo Ionization |
