Includes |
Attached Suspender Clip, Calibration Adapter and Tubing, Operating Instruction |
Features |
Standard TWA and STEL |
Gas Type |
NH3 |
Standards |
ANZEx: Ex ia I/IIC T4, ATEX Ex ia I/Ex ia IIC T4, China Ex: Ex ia I/IIC T4, Cl II, Gr E-G, CMA: Ex ia I, CSA: Cl I, Gr A-D T4, Equipment Group and Category I M1/II 1G, Ex ia IIC T4, IECEX: Ex ia I/IIC T4, INMETRO: Ex ia IIC T4,UL: Cl I, Div 1, Gr A-D, T4, KC: Ex ia I/IIC T4 |
Alarm Type |
Audible, Visual and Vibrating |
Detects |
Ammonia |
Sensor Range |
0 to 500 ppm |
Interchangeable Sensors |
Yes |
Battery Type |
CR2 Lithium |
Battery Life |
2,600 hr |
Resolution |
1 ppm |
Display |
Backlit LCD |
Alarm Setting |
Adjustable |
Status Indicator |
LED |
Temp. Range |
-40 Degrees to 140 Degrees F, -40 Degrees to 60 Degrees C |
Product Type |
Single-Gas Detector |
Series |
GasBadge Pro |
Operating Humidity - Maximum |
99 % |
Measurement Range |
Ammonia (0 to 500 ppm in 1 ppm) |
Resistance Properties |
Water Resistant |
Display Screen Type |
LCD |
Battery Voltage |
3 V |
Operating Humidity - Minimum |
0 % |
Battery Chemistry |
Lithium |
Gas Detected |
Ammonia |
Operating Temperature - Minimum |
-40 Degrees F |
Number of Gases Detected |
1 |
Housing Color |
Black |
Temperature Code |
T4 |
Housing Material |
Polycarbonate |
Operating Temperature - Maximum |
140 Degrees F |
Number of Batteries Required |
1 |
Alert Type |
Vibration |
Alarm Setting Adjustment |
Adjustable Alarm Setting |
Power Source |
Battery |
IP Rating |
IP64 |
Data Logger |
Yes |
Rechargeable Battery |
No |
Sensor Type |
Infrared |
Sensor Life |
1 yr (NH3) |
Includes Mounting Hardware |
Yes |
Alarm Volume Level |
95 dB |
Replaceable Battery |
Yes |
Includes Probe |
No |
Communication Protocol |
PC-Compatible Interface |
Maintainability |
Maintainable |
Chemical Formula |
CL2, CLO2, CO, CO/H2, H2, H2S, HCN, NH3, NO2, O2, PH3, SO2 |
Accuracy |
+/-10% (At Temperature of Calibration), +/-15% (Over Full Measurement Temperature) |
