| Item - Plugs and Receptacles |
Receptacle |
| Outlet Type - Plugs and Receptacles |
Standard Duplex |
| Application Environment |
Heavy Use Hospital Grade |
| Mounting Type - Plugs and Receptacles |
Flush |
| Amps - Plugs and Receptacles |
20 A |
| Voltage - Plugs and Receptacles |
125V AC |
| NEMA Receptacle Configuration - Plugs and Receptacles |
5-20R |
| Surge Suppression |
No |
| Tamper Resistant |
No |
| Sub-Category |
Duplex Receptacles |
| Power Indicator |
No |
| Standards |
CSA Certified C22.2 No. 42 File 285, Federal Specification W-C-596, NEMA WD-6, UL 498 File E2186 |
| Corrosion Resistant |
No |
| Description |
Slender/Compact |
| Weather Resistant |
No |
| Amps |
20 |
| Material |
Thermoplastic Polyester |
| Color - Plugs and Receptacles |
Red |
| NEMA Configuration |
5-20 |
| Color |
Rouge |
| Number of Wires |
3 |
| Wiring Method - Plugs and Receptacles |
Back and Side |
| Number of Gangs |
1 |
| Weather Resistant - Plugs and Receptacles |
No |
| Item |
Traditional Duplex |
| Voltage |
125VAC |
| Number of Poles |
2 |
| HP |
1 hp |
| Outlet Type |
Duplex |
| Mounting Type |
Flush |
| Phase |
Single Phase |
| Wiring Method |
Back, Side |
| IP Rating |
IP20 |
| Carton Quantity |
10 |
| Voltage Rating |
125 V |
| Amperage |
20 A |
| Number Of Wires |
3-Wire |
| Series |
Hospital Grade |
| Maximum Horsepower |
1 |
| Nema Rating |
5-20R |
| Type |
Duplex Receptacle |
| Number Of Poles |
2-Pole |
| Connectivity |
Back and Side Wired Screw Terminals |
| Current Rating |
20 A |
| Dielectric Strength |
Withstands 2,000V minimum |
| Brand |
Hubbell Wiring Device-Kellems |
| Style |
Slender/Compact |
| Contact Material |
Brass |
| Additional Electrical Protections |
Standard Protection |
| Mount Type |
Flush |
| Surge Protection |
No |
| NEMA Receptacle Configuration |
5-20R |
| AFCI |
No |
| Polarized |
Yes |
| Horsepower Rating |
1 hp |
| Number of Poles & Wires |
2 Pole / 3 Wire |
| Grade |
Hospital Grade Fed. Spec. |
| Grounding |
Grounded |
| Wire Connection Types |
Screw Terminals |
| Wire Connection Type |
Screw Terminals |
| GFCI |
No |
| Flange Type |
Non-Flanged |
| Cover Type |
No Cover |
| Housing Color |
Red |
| Shrouded |
No |
| NEMA Enclosure Rating |
1 |
| Market |
Commercial |
| Includes Mounting Hardware |
Yes |
| Additional Electrical Protection |
Standard Protection |
| Minimum Operating Temperature |
-40 Degrees F |
| UL 94 Flammability Rating |
V-0 |
| For Location |
Indoor |
| Housing Material |
Nylon |
| Connection Orientation |
Straight |
| Maximum Operating Temperature |
167 Degrees F |
| Key Resistance Properties |
Standard Resistance |
| Resistance Properties |
Impact Resistant |
| Includes |
Grounding Staple, Mounting Hardware, Wall Plate or Weatherproof Cover |
| Terminal Accommodation |
#12-#10 AWG stranded or solid copper wire only |
| Terminal Identification |
Terminals identified in accordance with UL 498 and CSA |
| Current Interrupting |
Certified for current interrupting at full rated current |
| Automatic Self-grounding Staple |
Stainless steel |
| Terminal Screws |
Brass |
| Mounting Screws |
Zinc plated steel |
| Mounting Strap |
.050 in. (1.3) Galvanized steel |
| Base |
PBT |
| Ground Contacts |
.031 in. (.8) Brass |
| Operating Temperatures |
Maximum continuous 75°C; minimum -40°C (w/o impact) |
| Contacts |
0.031" (0.8) Brass |
| Flammability |
UL 94 V-0 |
| Face |
Nylon |
| Device Color |
Red |
| Clamping Plate |
Nickel plated steel |
| Dielectric Voltage |
Withstands 2,000V minimum |
| Voltage Rating Description |
125 V |
| Wattage |
2500 W |
| Environmental Conditions |
Indoor Dry Unless Protected By Additional Means |
| Application |
Hospital Grade |
| Operating Temperature |
Maximum continuous 75°C and minimum -40°C without Impact |
| Performance |
Electrical - Current Interrupting - Certified for current interrupting at full rated current Electrical - Dielectric Voltage - Withstands 2,000V minimum Environmental - Flammability - UL 94 V-0 Environmental - Operating Temperatures - Maximum continuous 75°C, minimum -40°C (w/o impact) Mechanical - Product Identification - Ratings are a permanent part of the device Mechanical - Terminal Accommodation - #12-#10 AWG stranded or solid copper wire only Mechanical - Terminal Identification - Terminals identified in accordance with UL 498 and CSA |
| Item Type |
Traditional Duplex |
| Industry Standard(s) |
CSA Certified, C22.2, No. 42 File 285 Fed. Spec. W-C-596 NEMA® WD-6 Compliant UL Listed to UL498 File No. E2186 |
| Amperage Rating |
20 A |
| Horsepower - Maximum |
1 |
| Material - Mounting Hardware |
Screw Mounting |
| Current / Amperage Rating |
20 A |
| OEM Brand Name |
Hubbell Wiring Device-Kellems |
