| Voltage |
120 to 277V AC |
| Series |
GeoPak |
| Light Technology |
LED |
| Fixture Sensor Type |
No Sensor Included |
| Lumens |
5,678 lm |
| Green Environmental Attribute |
Product Contributes To Reducing Energy Consumption |
| Housing Color |
Bronze |
| Lumens Per Watt |
117.0 |
| Standards |
UL 1598, Wet Location Listed |
| Fixture Housing Material |
Aluminum |
| Warranty |
5 yr |
| Lamp Watts - Fixtures |
49.0 |
| Sensor Type - Fixtures |
No Sensor Included |
| Fixture Rated Life |
60,000 hr |
| Color Temp. |
5000K |
| Fixture Voltage |
120 to 277 |
| IP Rating |
IP65 |
| Fixture Lens Material |
No Lens |
| Operating Temp. Range |
-40 Degrees to 40 Degrees C |
| Light Distribution |
Type IV |
| Color Rendering Index |
70 |
| Color Temperature |
5000K |
| Fixture Housing Color |
Bronze |
| Lighting Certification |
DesignLights Consortium (DLC) |
| Description/Special Features |
Continuous 0-10V Dimming |
| Housing Finish |
Powder Coated |
| Max. Fixture Wattage |
49.0 |
| Type - Wall Pack Fixtures |
Architectural |
| Green Certification or Other Recognition |
DesignLights Consortium (DLC) |
| LED Replacement For |
200W HPS/MH |
| Housing Material |
Aluminum |
| Rated Life |
60,000 hr |
| Light Distribution Shape |
Type IV |
| Fixture Wattage |
50 W |
| Lumens per Watt |
117 lm/W |
| Special Features |
Continuous 0-10V Dimming |
| Min. Operating Temp. |
-40 Degrees F |
| Max. Operating Temp. |
104 Degrees F |
| Color Selectable |
Not Selectable |
| Light Output |
5,678 lm |
| Operating Temperature - Maximum |
104 Degrees F |
| Light Distribution Type - NEMA |
NEMA 4x4 |
| Mount Type |
Surface |
| Incandescent Wattage Equivalency |
200 W |
| Lumen Selectable |
Not Selectable |
| Number of Knockouts |
0 |
| Light Distribution Type - IESNA |
Type IV |
| Metal Halide Wattage Equivalency |
200 W |
| Number of Hubs |
1 |
| High Pressure Sodium Wattage Equivalency |
200 W |
| Operating Temperature - Minimum |
-40 Degrees F |
| Low Pressure Sodium Wattage Equivalency |
200 W |
