Hubbell CSB120I Wall Switch Toggle Switch, Single Pole, Ivory, 20 A, Screw Terminals - KVM Tools Inc.KV49YL39

Hubbell CSB120I Wall Switch Toggle Switch, Single Pole, Ivory, 20 A, Screw Terminals

UPC: 783585154046 | Harmonization / Schedule B : 8536.50.9040

Country of Origin: | Shipping Weight:

$12.19 - $12.19
$12.19
$12.19 - $12.19
$12.19
Wall Switch, Color Ivory, Current Rating 20 A, Switch Function Maintained, Switch Type Single Pole, Voltage Rating 120/277V AC, Wiring Method Back, Side, Horsepower Rating 1 hp, Locking Style Not Applicable, Maximum Wire Size 10 AWG, Minimum Wire Size 14 AWG, Number of Switches 1, Resistance Properties Shatter and Crack Resistant, Corrosion Resistant, Impact Resistant, Standards UL Listed, Switch Style Toggle, Wire Connection Type Screw Terminals, Housing Material Nylon, Market Commercial
Item Wall Switch
Switch Type Single Pole
Switch Style Toggle
Amps AC 20 A
Color Ivory
Voltage AC 120 to 277
Locking No
Switch Function Maintained
Wiring Method Back, Side
Application Environment Commercial
Rated HP 1
Antimicrobial No
Description/Special Features Quiet Switch
Standards UL Listed
Voltage 120/277V AC
Wire Connection Type Screw Terminals
Voltage Rating 120/277V AC
Current Rating 20 A
For Market Commercial Grade
Market Commercial
Horsepower Rating 1 hp
Number of Switches 1
Minimum Operating Temperature -40 Degrees F
Wire Connection Types Screw Terminals
Resistance Properties Shatter and Crack Resistant, Corrosion Resistant, Impact Resistant
Locking Style Not Applicable
Maximum Operating Temperature 75 Degrees C
Housing Material Nylon
Switch Material Nylon
Amperage 20A
Operating Temperature Max. continuous: 75°C; Min. continuous: -40°C without impact
Dielectric Voltage Withstands 1500V AC minimum for 1 minute
Toggle Color Ivory
Operating Temperatures Max Continuous- 75 Degrees C, Minimum- -40 Without Impact
Switch Grade Specification Grade
Listing and Certifications Listed to Standard UL 20, CSA Certified, Meets NEMA WD1
Terminal Accommodations #14 AWG min. - #10 AWG max. solid and stranded copper wire only
Product Type Toggle-switches
Overload Minimum 4.8 times rated current for 100 cycles
Max. Working Voltage 277V AC
Wiring Style Back and Side Wired
Switch Handle Positions 2
Temperature Rise 30°C maximum at rated current
Flammability UL 94V-2
Max. Continuous Current 20A
