Outlet Type - Plugs and Receptacles |
Standard Duplex |
Application Environment |
Commercial |
Mounting Type - Plugs and Receptacles |
Flush |
Amps - Plugs and Receptacles |
20 A |
Voltage - Plugs and Receptacles |
125V AC |
NEMA Receptacle Configuration - Plugs and Receptacles |
5-20R |
Surge Suppression |
No |
Tamper Resistant |
No |
Item |
Receptacle |
Amps - Plugs and Receptacles |
20 |
Amps |
20 |
NEMA Configuration |
5-20 |
Number of Gangs |
1 |
Wiring Method - Plugs and Receptacles |
Side |
Standards |
CSA Certified C22.2, Federal Specification W-C-596, NEMA WD-6, UL 498 |
Color - Plugs and Receptacles |
Ivory |
Mounting Type |
Flush |
Outlet Type |
Duplex |
Weather Resistant |
No |
Description |
Smooth |
Corrosion Resistant |
No |
Weather Resistant - Plugs and Receptacles |
No |
Number of Poles |
2 |
Voltage |
125VAC |
Power Indicator |
No |
HP |
1 hp |
Phase |
Single |
Color |
Ivory |
Number of Wires |
3 |
Material |
Nylon |
Wiring Method |
Side |
Sub-Category |
Duplex Receptacles |
Type |
Duplex |
UL 94 Flammability Rating |
V-2 |
Additional Electrical Protections |
Standard Protection |
Voltage Rating |
125V AC |
Additional Electrical Protection |
Standard Protection |
Maximum Operating Temperature |
167 Degrees F |
Market |
Commercial |
Key Resistance Properties |
Standard Resistance |
Polarized |
Yes |
Mount Type |
Flush |
Primary Resistance Properties |
20 A |
AFCI |
No |
Shrouded |
No |
Housing Material |
Nylon |
Wire Connection Types |
Screw Terminals |
Includes Mounting Hardware |
Yes |
Horsepower Rating |
1 hp |
Receptacle Type |
Duplex |
Grade |
Federal Specification |
Surge Protection |
No |
Connection Orientation |
Straight |
Housing Color |
Ivory |
NEMA Receptacle Configuration |
5-20R |
Flange Type |
Non-Flanged |
Includes |
Grounding Staple, Mounting Hardware, Wall Plate or Weatherproof Cover |
Cover Type |
No Cover |
Minimum Operating Temperature |
-40 Degrees F |
For Location |
Indoor |
Current Rating |
20 A |
Number of Poles & Wires |
2 Pole / 3 Wire |
GFCI |
No |
NEMA Enclosure Rating |
1 |
Contact Material |
Brass |
Grounding |
Grounded |
Wire Connection Type |
Screw Terminals |
Flammability |
UL 94 V-2 |
Temperature Rise |
Max 30°C temperature rise at full rated current after 50 cycles of overload at 150% of rated current at a power factor of 75%.. |
Power Contacts Material |
.031" (.8) Phosphor Bronze |
Terminal Accommodation |
#12-#10 AWG copper stranded or solid conductor only |
Operating Temperatures |
Maximum continuous 75°C; minimum -40°C (w/o impact) |
Mounting Strap Material |
.040" (1) Steel (Galvanized) |
Base Material |
Nylon |
Device Color |
Ivory |
Amperage |
20A |
Certification |
UL Listed, File E2186, Meets NEMA WD-6 requirements Listed to UL Standard 498, Certified to CSA, C22.2, No. 42 |
Current Interrupting |
Certified for current interrupting at full rated current |
Other Available Colors |
Brown, Almond, Black, Gray, Ivory, Office White, White, Light Almond |
Top Material |
Nylon |
Receptacle Grade |
Commercial Series Specification Grade |
Receptacle Style |
Duplex |
Face Style |
Smooth Face |
Poles and Wires |
2 Pole, 3-Wire Grounding |
Mounting Screw Material |
Steel-Zinc Plated |
Auto Ground Clip Material |
.032" (.8) Steel Wire |
Terminal Screw Material |
#8-32 Brass, Multiple Drive |
Ground Screw Material |
#8-32 Brass, Multiple Drive (Green) |
Rating |
20A, 125V |
Horsepower |
1 |
Dielectric Voltage |
Withstands 2,000V minimum |
NEMA No. |
5-20R |
Terminal Identification |
Terminals identified in accordance with UL 498 and CSA |
Face Shape |
Traditional |
Standard |
NEMA |
Current / Amperage Rating |
20 A |
OEM Brand Name |
Hubbell Wiring Device-Kellems |
Series |
Commercial Specification Grade |
Application |
Commercial Specification Grade |
Wattage |
2500 W |
Dielectric Strength |
Withstands 2,000V minimum |
Operating Temperature |
Maximum continuous 75°C and minimum -40°C without Impact |
Voltage Rating Description |
125 V |
Performance |
Electrical - Current Interrupting - Certified for current interrupting at full rated current Electrical - Dielectric Voltage - Withstands 2,000V minimum Environmental - Flammability - UL 94 V-2 Environmental - Operating Temperatures - Maximum continuous 75°C minimum -40°C (w/o impact) Mechanical - Product Identification - Ratings are a permanent part of the device Mechanical - Terminal Accommodation - #12-#10 AWG copper stranded or solid conductor only Mechanical - Terminal Identification - Terminals identified in accordance with UL 498 and CSA |
Item Type |
Traditional Duplex |
Amperage Rating |
20 A |
Industry Standard(s) |
Certified to CSA, C22.2, No. 42 Fed. Spec. W-C-596 NEMA® WD-6 Compliant UL Listed to UL498 File No. E2186 |
Connectivity |
Side Wired |
Environmental Conditions |
Indoor Dry Unless Protected By Additional Means |
Material - Mounting Hardware |
Screw Mounting |
Nema Rating |
5-20R |
Style |
Smooth Face |
Horsepower - Maximum |
1 |
