| Resolution |
1% LEL, Carbon Monoxide 1 ppm, Hydrogen Sulfide 1 ppm, Oxygen 0.1% vol |
| Operating Temp. Range |
-20 Degrees to +50 Degrees C (-4 Degrees to +122 Degrees F) |
| Item |
Multi-Gas Detector |
| Alarm Type |
Audible, Vibrating, Visual |
| Battery Life |
18 hr |
| Sensor Range |
CO 0 to 500 ppm, H2S 0 to 100 ppm, LEL 0 to 100% 0 to 5.0% v/v, O2 0 to 30.0% |
| Alarm Setting |
Hydrogen Sulfide (High 15 ppm, Low 10 ppm), Oxygen (High 23.5%, Low 19.5%), Carbon Monoxide (High 200 ppm, Low 35 ppm), LEL (High 50%, Low 10%) |
| Standards |
ATEX CE Ex II 1G Ex ia IIC T4 Ga, CSA Certified, CE Certified, IECEX: Ex ia IIC T4 Ga |
| Housing Color |
Yellow |
| Includes |
Calibration Cap and Hose, Concussion Proof Housing, Multi-Language CD Manual, Screwdriver, Stainless Steel Alligator Clip |
| Features |
One Button Operation, Extended Battery Life, Especially in Cold Weather, Slim and Compact, Visual Compliance with Flashing Green IntelliFlash |
| Green Environmental Attribute |
Product is Rechargeable |
| IP Rating |
IP68 |
| Power Source |
Battery |
| Chemical Formula |
CO, H2S, O2 |
| Includes Probe |
Yes |
| Sub-Brand |
BW |
| Battery Chemistry |
Lithium Ion |
| Replaceable Battery |
Yes |
| Includes Batteries |
Yes |
| Temperature Code |
T4 |
| Gas Detected |
Carbon Monoxide, Combustible Gas, Hydrogen Sulfide, Oxygen |
| Display Screen Type |
LCD |
| Number of Gases Detected |
4 |
| Communication Protocol |
PC-Compatible Interface, Wireless |
| Includes Charger |
Yes |
| Alert Type |
Light, Sound, Vibration |
| Series |
BW MicroClip |
| Rechargeable Battery |
Yes |
| Mount Type |
Portable/Handheld |
| Operating Temperature - Minimum |
-4 Degrees F |
| Data Logger |
Yes |
| Resistance Properties |
Water Resistant |
| Alarm Setting Adjustment |
Adjustable Alarm Setting |
| Measurement Range |
Carbon Monoxide (0 to 500 ppm), Hydrogen Sulfide (0 to 100 ppm), LEL 0 to 100% 0 to 5% vol, Oxygen (0 to 30% vol) |
| Display Type |
Digital |
| Sensor Life |
3 yr |
| Hazardous Location Specification |
Class I Divisions 1 Groups A, B, C, D |
| Operating Temperature - Maximum |
122 Degrees F |
