Honeywell DT-2R-A7 Snap Action Switch, Plunger Actuator, 2NO/2NC, Screw Terminals, DT Series

Honeywell DT-2R-A7 Snap Action Switch, Plunger Actuator, 2NO/2NC, Screw Terminals, DT Series

UPC: | Harmonization / Schedule B : 8536509065

Country of Origin: Mexico | Shipping Weight: 0.5 lb

$240.93 - $240.93
$240.93
$240.93 - $240.93
$240.93

Snap Action Switch, Pin Plunger Actuator, DC Contact Rating 10 A @ 24 V, Contact Form DPDT, Height 1 in, Width 2 in, Depth 0.7 in, Electrical Connection Screw, Mounting Dimension 1.00 in Centers, Series DT, Honeywell Industrial DT-2R-A7

Actuator Type Pin, Plunger
DC Contact Rating 10 A @ 24 V
Contact Form DPDT
Release Force 2 ozf
Housing Material General Purpose Phenolic
Voltage Rating 24VDC
Series DT
Operating Temp. Range -67 Degrees to 185 Degrees F
AC Contact Rating 10 A @ 125 V, 10 A @ 250 V
Connection Screw Terminal
Type Basic Limit Switch
Head Action Spring Return, Standard
Operator Configuration Pin
Body Material Phenolic
Country of Origin Mexico
