GE FBN36TE090R Molded Case Circuit Breaker, 90 A, 3 Pole, 600V AC, 150kA at 240V AC

GE FBN36TE090R Molded Case Circuit Breaker, 90 A, 3 Pole, 600V AC, 150kA at 240V AC

UPC: 783164336726 | Harmonization / Schedule B : 8536.20.0020

Country of Origin: United States | Shipping Weight: 3.25 lbs

$4,432.84 - $4,432.84
$4,432.84
$4,432.84 - $4,432.84
$4,432.84

Molded Case Circuit Breaker, 90 A Amps, AC Voltage Rating 347/600V AC, Max. AIR Rating 150kA at 240V AC, For Use With GE Panelboards, Series FBN, Circuit Breaker Type Standard, Number of Poles 3, DC Voltage Rating Not Rated, Terminal Connection Lug, Trip Type Thermal Magnetic, Phase Three, Instantaneous Trip Fixed, Phase Connection ABC, Frame Size 100A/FB, Circuit Breaker Mounting Style Free Standing, Height 6.45 in, Width 4.11 in, Depth 3.88 in, Min. Wire Size 4 AWG, Max. Wire Size 1/0 AWG

Series FBN
Amps 90A
Number of Poles 3
AC Voltage Rating 347/600V AC
Circuit Breaker Type Standard
Phase 3
Circuit Breaker Actuator Toggle
Circuit Breaker Mounting Style Free Standing
Max. AIR Rating 65kA at 480V AC
Trip Type Thermal Magnetic
Instantaneous Trip Fixed
Terminal Connection Lugs
Phase Connection ABC
DC Voltage Rating Not Rated
Standards UL Listed
For Use With GE Panelboards
Country of Origin United States
