| Includes |
Alligator Clips, Stackable Test Leads, Test Leads |
| Standards |
ASNI/ISA S82.01-1994, CAN/CSA C22.2 No 1010.1:1992, EN 61010-1:1993 |
| Calibration Certificate |
NIST |
| Thermocouple Type |
B, BP, E, J, K, L, N, R, S, T, U, XK |
| RTD Type |
Cu10, Ni120, Pt100 (385), Pt100 (391-JIS), Pt100 (392), Pt1000 (385), Pt200 (385), Pt500 (385) |
| Safety Rating |
ANSI/ISA S82.01-1994, CAN/CSA C22.2 No 1010.1:1992, EN61010-1:1993 |
| Current Measurement Range |
0 to 24 mA DC |
| Source Voltage |
-10 to 75 mV |
| Powered By |
(4) AA Batteries |
| Pressure Modules |
29 |
| Measurement Functions |
Hertz, mV, Ohms, V |
| Frequency Source Range |
10.0 to 15.0 kHz |
| Intrinsically Safe |
No |
| Source Current |
24 mA DC |
| Voltage Measurement Range |
-10 to 75 mV |
| Loop Supply Voltage |
24 V |
| Basic DC Accuracy |
+/- 0.01% + 2mV |
| Max. Loop Current |
22 mA |
| Resistance Measurements |
0 to 4,000 ohm |
| Resistance Source |
1,500 to 4,000 ohm |
| Thermocouple Temperature Range |
-250 Degrees to 2500 Degrees C |
| Source/Simulate |
Hertz, mA, mV, Ohms, V |
| Frequency Measurement Range |
10.0 to 15.0 kHz |
| Number of Batteries Required |
4 |
| Resistance Measurement - Minimum |
0 ohm |
| Parameters Measured |
DC Current, DC Voltage, Frequency, Pressure, Resistance, RTD, TC |
| Resistance Measurement - Maximum |
4,000 ohm |
| Source Current - Maximum |
24 mA |
| Frequency Measurement - Minimum |
1 kHz |
| Source Frequency - Minimum |
10 kHz |
| Source Voltage - Maximum |
75 mV |
| Current Measurement - Maximum |
24 mA |
| Frequency Measurement - Maximum |
15 kHz |
| Battery Chemistry |
Alkaline |
| Voltage Measurement - Maximum |
75 mV |
| Loop Current - Maximum |
22 mA |
| Current Measurement - Minimum |
0 mA |
| Thermocouple Temperature - Minimum |
482 Degrees F |
| Source Resistance - Minimum |
1,500 ohm |
| Parameters Sourced |
AC Voltage, DC Voltage, Frequency, Resistance |
| Source Resistance - Maximum |
4,000 ohm |
| Intrinsic Safety |
Not Specified Intrinsically Safe |
| Thermocouple Temperature - Maximum |
4,532 Degrees F |
| Source Voltage - Minimum |
-10 mV |
| Includes Batteries |
Batteries Included |
| Calibration Certificate Type |
NIST |
| Source Frequency - Maximum |
15 kHz |
| Digital Display Screen Type |
LCD with Backlight |
| Source Current - Minimum |
0.001 mA |
| Voltage Measurement - Minimum |
-10 mV |
| Communication Protocol |
HART |
