| Display Type |
LCD |
| Includes |
Alligator Clips, Safety-Designed Test Lead Set |
| Standards |
ANSI/ISA S82.01-1994, CAN/CSA C22.2 No 1010.1-92, IEC 1010-1 |
| Voltage Measurement Range |
0 to 1000V AC/DC |
| Amps AC |
1 A |
| Basic DC Accuracy |
0.2% + 2 LSD (DC) |
| Source/Simulate |
mA |
| Voltage (AC) |
400mV/4/40/400/1000 |
| Measurement Functions |
F, mA, Ohms, V |
| Amps DC |
30mA/1A |
| Accuracy |
+/-0.5% + 2 Digits |
| Intrinsically Safe |
No |
| True RMS |
Yes |
| Current Measurement Range |
0 to 30 mA DC |
| Resistance (Ohms) |
400/4K/40K/400K/4M/40M |
| Source Current |
0 to 20mA DC |
| Loop Supply Voltage |
24 V DC |
| Frequency Range (Hz) |
.01 Hz to19.999 K |
| Voltage (DC) |
400mV/4/40/400/1000 |
| Temp. Range |
-200 °C to 1372 °C using the t3000 FC |
| Interface |
Wireless |
| Parameters Sourced |
DC Current, Resistance |
| Battery Chemistry |
Alkaline |
| Current Measurement - Minimum |
0 mA |
| Source Current - Minimum |
0 mA |
| CAT Safety Rating |
CAT III 1000V, CAT IV 600V |
| Voltage Measurement - Maximum |
1,000 V AC/DC |
| AC Magnitude Calculation |
True RMS |
| Current Measurement - Maximum |
30 mA |
| Calibration Certificate Type |
Not Certified |
| IP Rating |
IP42 |
| Loop Current - Maximum |
20 mA |
| Number of Batteries Required |
4 |
| Parameters Measured |
AC Current, AC Voltage, Continuity, DC Voltage, Diode, Frequency |
| Voltage Measurement - Minimum |
0 V AC/DC |
| Source Current - Maximum |
20 mA |
| Batteries Included |
Batteries Included |
| Maximum Frequency Measurement |
19.999 kHz |
| Maximum Resistance Measurement |
40 megaohm |
| Minimum Frequency Measurement |
0.5 Hz |
