| Accuracy |
+/-0.05% |
| Process Connection Location |
Bottom |
| Process Connection Type |
NPT |
| Digital Pressure and Vacuum Gauge Type |
Digital Compound Gauge |
| Application |
Hydraulics, Pneumatics |
| Gauge Case Material |
Cast Zinc Aluminum |
| Series |
700G |
| Lens Material |
Polycarbonate |
| Primary Pressure Range |
-14 to 0 to 10,000 |
| Primary Scale Units |
psi |
| IP/NEMA Rating |
IP67 |
| Hazardous Location Rating |
Not Rated |
| Panel-Mountable |
No |
| Blowout Safety Back |
No |
| Calibration Certificate |
NIST Traceable |
| Socket Material |
Stainless Steel |
| Case Color |
Yellow |
| Peak Hold |
No |
| Agency Compliance |
CSA: Class 1, Div2, Groups A-D rating, ATEX: rating II 3 G Ex nA IIB T6 |
| Powered By |
(3) AA Batteries |
| Includes |
Manual on CD-ROM in 14 languages |
| Display |
Multiline LCD |
| Number of Display Digits |
5 |
| Pressure Range |
-14 to 10,000 psi |
| For Use With |
Any Liquids or Gasses Compatible with 316 Stainless Steel |
| Display Units |
bar, psi |
| Connection Type |
MNPT |
| Wetted Materials |
Stainless Steel |
| Standards |
ATEX, CSA |
| Process Connection Gender |
Male |
| Process Temperature Range |
-14 Degrees to 131 Degrees F |
| Display Resolution |
0.01 bar |
| Includes Calibration Certificate |
Yes |
| Includes Batteries |
No |
| Non-Sparking |
No |
| Auto-Shutoff |
Yes |
| Case Shape |
Round |
| Accuracy Grade Gauge Type |
Process |
| Ambient Operating Temperature Range |
-10 Degrees to 55 Degrees C, 14 Degrees to 131 Degrees F |
| Bar Graph |
20 Segments |
| Primary Display Range |
-14 to 10,000 |
| Backlit Screen |
Yes |
| Languages |
English |
| Includes Rubber Boot |
No |
| Case Construction |
Rugged |
| Memory Storage Capacity |
8493 Readings |
| Primary Display Units |
psi |
| Compatible Manufacturer Model Number |
700HTPK, 700PTPK |
| Pressure Gauge Type |
Test Pressure Gauge |
| Pressure Range Type |
Compound |
| Weatherproof |
No |
| Compatible Process Media |
Any Clean Dry Non-Corrosive Gas, Any Liquids or Gases Compatible With 316 Stainless Steel, Any Non-Flammable, Non-Toxic, Non-Explosive, Non-Oxidizing Liquid or Gas Compatible With 316 Stainless Steel |
| Display Range |
-14 to 10,000 psi |
| Adjustable Set Points |
No |
| Compatible Brand and Series |
Fluke 700 Series |
| Burst Pressure |
20,000 psi |
| Power Source |
Battery |
| Includes Mounting Hardware |
No |
| Low Battery Indicator |
Yes |
| Automatic Shut-Off Time |
1 min, 30 min |
| Battery Life |
1,500 hr |
| Display Type |
LCD |
| Operating Temperature Range |
-14 Degrees to 131 Degrees F |
