Enerpac RC50 Hydraulic Ram Single Acting, 5 ton Nominal Capacity, 5/8 in Nominal Stroke Lg, Steel, RC
UPC: 662005300549 | Harmonization (Schedule B): 8412.21.0075
SKU KV3KD48
Original price
$529.37
-
Original price
$529.37
Original price
$529.37
$529.37
-
$529.37
Current price
$529.37
Hydraulic Ram, Single Acting, General Purpose, Steel, Nominal Capacity 5 ton, Max. Push Capacity 5 ton, Stroke Length 5/8 in, Nominal Stroke Length 5/8 in, Effective Push Area 0.99 sq in, Max. Pressure 10,000 psi, Oil Capacity Push 0.62 cu in, Retracted Height 1.63 in, Extended Height 2.25 in, Outside Dia. 2.31 in, Plunger Dia. 1 in, Plunger Thread Size 3/4 In.-16, Collar Thread Size 3-5/16 In.-12, Base Bolt Circle Dia. 1 in, Center Hole Dia. 1 in, Series RC, Includes Coupler, Dust Cap
| Effective Area | 1.00 sq. in. |
| Weight Capacity | 5 tons |
| Item | Hydraulic Ram |
| Cylinder Type | General Purpose |
| Body Material | Steel |
| Handle | Yes |
| Includes | Coupler, Dust Cap |
| Max. Pressure | 10,000 psi |
| Single Acting/Double Acting | Single Acting |
| Oil Capacity | 0.62 cu. in. |
| Effective Push Area | 0.99 sq in |
| Nominal Capacity | 5 ton |
| Oil Capacity Push | 0.62 cu in |
| Series | RC |
| Max. Push Capacity | 5 ton |
| Finish | Paint |
| Type | General Purpose |
