Enerpac RC50 Hydraulic Ram Single Acting, 5 ton Nominal Capacity, 5/8 in Nominal Stroke Lg, Steel, RC

UPC: 662005300549 | Harmonization (Schedule B): 8412.21.0075

SKU KV3KD48
Original price $529.37 - Original price $529.37
Original price
$529.37
$529.37 - $529.37
Current price $529.37
Hydraulic Ram, Single Acting, General Purpose, Steel, Nominal Capacity 5 ton, Max. Push Capacity 5 ton, Stroke Length 5/8 in, Nominal Stroke Length 5/8 in, Effective Push Area 0.99 sq in, Max. Pressure 10,000 psi, Oil Capacity Push 0.62 cu in, Retracted Height 1.63 in, Extended Height 2.25 in, Outside Dia. 2.31 in, Plunger Dia. 1 in, Plunger Thread Size 3/4 In.-16, Collar Thread Size 3-5/16 In.-12, Base Bolt Circle Dia. 1 in, Center Hole Dia. 1 in, Series RC, Includes Coupler, Dust Cap
Effective Area 1.00 sq. in.
Weight Capacity 5 tons
Item Hydraulic Ram
Cylinder Type General Purpose
Body Material Steel
Handle Yes
Includes Coupler, Dust Cap
Max. Pressure 10,000 psi
Single Acting/Double Acting Single Acting
Oil Capacity 0.62 cu. in.
Effective Push Area 0.99 sq in
Nominal Capacity 5 ton
Oil Capacity Push 0.62 cu in
Series RC
Max. Push Capacity 5 ton
Finish Paint
Type General Purpose
