| For Use With |
All Cylinders |
| Gauge Application |
High Cycle |
| Includes |
Pressure Equalizing Membrane, Safety Blow-Out Disk |
| Range |
0 to 10,000 psi |
| Accuracy |
+/-1.50% |
| Material |
Stainless Steel |
| Color |
Silver |
| Application |
Hydraulics |
| Max Pressure (PSI) |
10000 |
| Gauge Primary Range Values |
0 to 10,000 |
| Gauge Primary Range Units |
psi |
| Gauge Connection Type |
NPTF |
| Basic Gauge Case Material |
Stainless Steel |
| Case Color |
Metallic |
| Gauge Case Color |
Stainless Steel |
| Calibration Certificate Included |
No |
| Gauge Accuracy |
+/-1.50% |
| Gauge Lens Material |
Plastic |
| Gauge Primary Range Smallest Graduation |
200 |
| Smallest Graduation |
200 psi |
| Basic Gauge Lens Material |
Glass |
| Gauge Case Material |
Stainless Steel |
| Gauge Panel Mountable |
No |
| Required Gauge Adapter |
Enerpac GA-3 |
| Liquid Filled |
Yes |
| Series |
G |
| Max. Pressure (PSI) |
10000 |
| Gauge Filled With |
Glycerin |
| Gauge Connection Location |
Bottom |
| Pressure and Vacuum Gauge Type |
Pressure Gauge |
| Socket Material |
303 Stainless Steel |
| Graduations |
200 psi x 10 bar |
| Gauge Mounting Method |
Lower Mount |
| Pressure Range |
0 to 10,000 psi |
| Process Connection |
1/4 in NPTF Male |
| Field Fillable |
No |
| Lens Material |
Polycarbonate |
| Secondary Pressure Range |
0 to 700 psi |
| Primary Units |
psi |
| IP/NEMA Rating |
Not Rated |
| Gauge Wetted Parts |
Stainless Steel / Copper |
| Compatible Brand and Series |
ENERPAC FM-25NG, ENERPAC NV-251 |
| Hydraulic Pressure Gauge Type |
Dial Pressure Gauge for Hydraulic Systems |
| Sensor Material |
Copper Alloy |
| Dial Color |
White |
| Secondary Range |
0 to 700 bar |
| Primary Scale Units |
psi |
| Liquid-Filled Case |
Yes |
| Case Construction |
Corrosion Resistant |
| Primary Range |
0 to 10,000 |
| Process Connection Type |
NPTF |
| Primary Pressure Range |
0 to 10,000 psi |
| Scale Type |
Dual |
| Requires Adapter |
Yes |
| Panel-Mountable |
No |
| Hazardous Location Rating |
Not Rated |
| Secondary Scale Minor Graduations |
10 |
| Process Connection Location |
Bottom |
| Process Connection Gender |
Male |
| Adjustable Pointer |
No |
| Blowout Safety Back |
Yes |
| Compatible Cylinder/Press |
All Cylinders |
| Compatible Gauge Adapter |
Enerpac GA-3 |
| Removable Bezel |
No |
| Pressure Range Type |
Pressure |
| Includes Vent Plug |
No |
| Compatible Manufacturer Model Number |
FM-25NG, NV-251 |
| Includes Mounting Hardware |
No |
| Sensor Type |
Bourdon Tube |
| Secondary Units |
bar |
| Gauge Case Liquid |
Glycerin |
| Pressure Gauge Type |
Hydraulic Cylinder Pressure Gauge |
| Vibration Resistance |
Liquid-Filled |
| Freeze Resistant Movement |
No |
| Secondary Scale Units |
bar |
| Accuracy Scale |
Full Scale |
| Primary Scale Minor Graduations |
200 |
| Gauge Mounting Type |
Stem-Mount |
