Eaton ED3125 125A 3-Pole Molded Case Circuit Breaker

Eaton ED3125 Molded Case Circuit Breaker, ED Series, 125A, 3-Pole, 240V AC, 65kA AIR, Thermal Magnetic

UPC: 786679455326 | Harmonization / Schedule B : 8536.20.0020

Country of Origin: Dominican Republic | Shipping Weight: 6 lbs

$2,620.13 - $2,620.13
$2,620.13
$2,620.13 - $2,620.13
$2,620.13

Molded Case Circuit Breaker, 125 A Amps, AC Voltage Rating 240V AC, Max. AIR Rating 65kA at 240V AC, Series ED, High Amp Trip Setting 225 A, Low Amp Trip Setting 15 A, Circuit Breaker Type Standard, Number of Poles 3, DC Voltage Rating 125V DC, Terminal Connection Load Side Lug, Trip Type Thermal Magnetic, Phase Three, Instantaneous Trip Fixed, Phase Connection ABC, Frame Size 225A/F

Series ED
Amps 125A
Number of Poles 3
AC Voltage Rating 240V AC
Circuit Breaker Type Standard
Phase 3
Circuit Breaker Actuator Toggle
Circuit Breaker Mounting Style Free Standing
Max. AIR Rating 65kA at 240V AC
Trip Type Thermal Magnetic
Instantaneous Trip Fixed
Terminal Connection Lugs
Phase Connection ABC
DC Voltage Rating 125V DC
High Amp Trip Setting 225 A
Standards CSA Certified, IEC Rated, UL Listed
Low Amp Trip Setting 15 A
Frame Type Complete Breaker
Interrupt Rating 65 kA at 240V AC
Max. Operating Temp. 158 Degrees F
Min. Operating Temp. -4 Degrees F
Certifications UL Listed
Country of Origin Dominican Republic
