Boston Gear F842B-10K-B9-M1 Speed Reducer, C-Face, 180TC/210C, 10:1

UPC: 884107027128 | Harmonization / Schedule B : 8483.40.5010

Country of Origin: United States | Shipping Weight: 36 lbs

$2,317.62 - $2,317.62
$2,317.62
$2,317.62 - $2,317.62
$2,317.62
Speed Reducer, Input Connection Type C-Face, Gear Type Helical, Output Shaft Type Round, Maximum Output Speed 175 RPM, Motor Frame Designation 180TC/210C, Base to Center 1.97 in, Gear Ratio 10:1, Rotation CW/CCW, Maximum Input Horsepower 3 hp, Maximum Output Torque 1006 in-lb, Overhung Load Capacity 525 ft-lb, Mounting Orientation Horizontal, Vertical, Bearing Type Ball, Maximum Input Speed 1,750 RPM, Gear Material Hardened and Ground Steel
Item Speed Reducer
Nominal Ratio 10:1
Input RPM 1750 RPM
Nominal Output RPM 175 RPM
Standards BISSC Certified; AGMA Service Class I
Number of Stages 1
Single/Double Output/Universal Single Output
Max. Output Torque 1,006 in-lb
Solid/Hollow Output Shaft Solid
Overhung Load 525 lb
Mounting Base
Max. Input HP 3 hp
Pinion Material Hardened Steel
Finish Powdered Epoxy Paint
Shaft Orientation Parallel Inline
Seal Type Double Lip
Lubrication Klubersynth UH1 6-460
Gear Material Hardened and Ground Steel
Output Torque @ 1/40 HP 3600 in.-lb.
Gear Type Helical
Frame 180TC/210C
Rotation CW/CCW
Housing Material Cast Iron
Reducer Model No. F842B-10K-B9
Speed Reducer Type C-Face
Bearings Ball
Output Torque @ 4 HP 1006 in-lb
Duty Standard
Nominal Output rpm 175 rpm
Motor Frame Designation 180TC/210C
Overhung Load Capacity 525 ft-lb
Housing Material Finish Powder Coated Epoxy Paint
Bearing Type Ball
Maximum Output Speed 175 RPM
Output Shaft Type Round
Maximum Output Torque 1006 in-lb
Base to Center 1.97 in
Gear Ratio 10:1
Maximum Input Speed 1,750 RPM
Input Connection Type C-Face
Mounting Orientation Horizontal, Vertical
Maximum Input Horsepower 3 hp
