| Gauge Application |
Process |
| Range |
0 to 30 psi |
| Accuracy |
+/-0.5% |
| Material |
Phenolic |
| Color |
Black |
| Application |
Chemical Industries, Refrigeration, Mining, Oil and Gas Industry, Power Industries, Turbines and Compressors, Water Purification or Irrigation, Water Pressure Testing |
| Gauge Primary Range Values |
0 to 30 |
| Gauge Primary Range Units |
psi |
| Gauge Connection Type |
MNPT |
| Basic Gauge Case Material |
Plastic |
| Case Color |
Black |
| Basic Gauge Lens Material |
Glass |
| Graduations |
5 psi |
| Gauge Lens Material |
Glass |
| Gauge Connection Location |
Bottom |
| Operating Temp. Range |
-40 Degrees to 150 Degrees F |
| Gauge Case Color |
Stainless Steel |
| Calibration Certificate Included |
No |
| Max. Pressure (PSI) |
30 |
| Gauge Socket Material |
316 Stainless Steel |
| Liquid Filled |
No |
| Gauge Primary Range Smallest Graduation |
0.2 |
| Gauge Special Options |
PLUS!(TM) Performance |
| Basic Gauge Sensor Material |
Stainless Steel |
| Basic Gauge Socket Material |
Stainless Steel |
| Basic Gauge Wetted Parts |
Stainless Steel |
| Gauge Panel Mountable |
Yes |
| Series |
1279 |
| Gauge Mounting Method |
Surface |
| Pressure and Vacuum Gauge Type |
Pressure Gauge |
| Gauge Case Material |
Phenolic |
| Gauge Accuracy |
+/-0.50% |
| Smallest Graduation |
0.2 psi |
| Gauge Sensor Material |
316 Stainless Steel |
| Socket Material |
316L Stainless Steel |
| Pressure Range |
0 to 30 psi |
| Case Material |
Phenolic |
| Process Connection |
1/2 in NPT Male |
| Standards |
ASME, CRN, UL 94-V-0 |
| Primary Scale Minor Graduations |
0.2 |
| IP/NEMA Rating |
Not Rated |
| Primary Scale Units |
psi |
| Liquid-Filled Case |
No |
| Case Construction |
Solid Front with Pressure Relief Back |
| Panel Mount Characteristics |
3 0.218 Dia Holes on 5 3/8 Dia Bolt Circle |
| Process Connection Location |
Bottom |
| Lens Material - Gauge |
Glass |
| Sensor Type |
Bourdon Tube |
| Compatible Process Media |
Chemical and Petrochemical, Metals, Natural Gas and LNG, Oil and Gas, Water and Wastewater |
| Dial Color |
White |
| Gauge Case Liquid |
None |
| Cleaned for Oxygen Service |
No |
| Hazardous Location Rating |
Not Rated |
| Dial Face Material |
Aluminum |
| Pressure Gauge Type |
Process Pressure Gauge |
| Pressure Range Type |
Pressure |
| Movement Type |
Rotary |
| Non-Sparking |
No |
| Freeze Resistant Movement |
No |
| Ambient Operating Temperature Range |
-20 Degrees to 200 Degrees F (-29 Degrees to 93 Degrees C) |
| Panel-Mountable |
No |
| Scale Type |
Single |
| Sensor Material |
316L Stainless Steel |
| Movement Material |
400 Stainless Steel |
| Process Connection Type |
NPT |
| Process Temperature Range |
-20 Degrees to 250 Degrees F |
| Includes Vent Plug |
No |
| Primary Pressure Range |
0 to 30 |
| Includes Mounting Hardware |
No |
| Pointer Material |
Aluminum |
| Dry Dampening Feature |
PLUS! Performance |
| Gauge Accuracy Grade |
Grade 2A - Process |
| Blowout Safety Back |
Yes |
| Gauge Wetted Parts |
Stainless Steel |
| Bezel Material |
Polycarbonate |
| Removable Bezel |
Yes |
| Burst Pressure |
1,400 psi |
| Lens Material |
Glass |
| Field Fillable |
No |
| Dial Face Color |
White |
| Primary Pressure Scale Color |
Black |
| Accuracy Scale |
Full Scale |
| Includes Calibration Certificate |
No |
| Bezel Mounting Type |
Threaded |
| Process Connection Gender |
Male |
| Pointer Characteristics |
Micrometer Adjustable |
| Vibration Resistance |
Dry Case Vibration-Dampened |
| Accuracy Grade |
ASME B40.100 Grade 2A |
