| Connection Location |
Back |
| Item |
Commercial Pressure Gauge |
| Gauge Application |
Compressors, Filter Regulators, Fluid Power Equipment, Medical Equipment, Pool and Spa Filters, Automotive Diagnostic Equipment, Beverage Dispensing Equipment, Industrial Machinery, A Variety of Other Applications |
| Range |
0 to 60 psi |
| Accuracy |
+/-3-2-3% |
| Material |
ABS |
| Color |
Black |
| Gauge Primary Range Values |
0 to 60 |
| Gauge Primary Range Units |
psi |
| Gauge Connection Type |
MNPT |
| Basic Gauge Case Material |
Plastic |
| Case Color |
Black |
| Gauge Socket Material |
Brass |
| Smallest Graduation |
0.5 psi |
| Liquid Filled |
No |
| Calibration Certificate Included |
No |
| Pressure and Vacuum Gauge Type |
Pressure Gauge |
| Gauge Case Color |
Black |
| Gauge Panel Mountable |
No |
| Gauge Primary Range Smallest Graduation |
0.5 |
| Graduations |
5 psi |
| Basic Gauge Lens Material |
Plastic |
| Gauge Sensor Material |
Bronze |
| Gauge Connection Location |
Center Back |
| Gauge Case Material |
ABS Plastic |
| Series |
1005P |
| Gauge Accuracy |
+/-3-2-3% |
| Basic Gauge Wetted Parts |
Brass / Bronze |
| Max. Pressure (PSI) |
60 |
| Gauge Lens Material |
Polycarbonate |
| Operating Temp. Range |
-40 Degrees to 150 Degrees F |
| Basic Gauge Socket Material |
Brass |
| Basic Gauge Sensor Material |
Bronze |
| Socket Material |
Brass |
| Case Material |
Plastic |
| Sensor Material |
Bronze |
| Hazardous Location Rating |
Not Rated |
| Blowout Safety Back |
No |
| Process Connection Gender |
Male |
| Includes Vent Plug |
No |
| Gauge Wetted Parts |
Brass / Bronze |
| Compressed Gas Pressure Gauge Type |
Indicating Dial Pressure Gauge |
| Panel-Mountable |
No |
| Dial Face Material |
Aluminum |
| Field Fillable |
No |
| Primary Units |
psi |
| Gauge Case Liquid |
None |
| Burst Pressure |
1,600 psi |
| Gauge Accuracy Grade |
Grade B - Commercial |
| Pointer Material |
Aluminum |
| Pressure Range Type |
Pressure |
| Primary Scale Minor Graduations |
0.5 |
| Movement Material |
Polyester |
| Ambient Operating Temperature Range |
-40 Degrees to 150 Degrees F, -40 Degrees to 65 Degrees C |
| Pointer Color |
Black |
| Dry Dampening Feature |
FlutterGuard |
| Includes Mounting Hardware |
No |
| Accuracy Scale |
Mid-Scale |
| Lens Material - Gauge |
Plastic |
| Vibration Resistance |
Liquid-Filled |
| Lens Material |
Polycarbonate |
| Removable Bezel |
No |
| Primary Pressure Scale Color |
Black |
| Scale Type |
Single |
| Compatible Process Media |
Water |
| Dial Color |
Green/Yellow/Red |
| Non-Sparking |
No |
| Process Temperature Range |
-40 Degrees to 150 Degrees F |
| Process Connection Location |
Center Back |
| IP/NEMA Rating |
Not Rated |
| Freeze Resistant Movement |
No |
| Liquid-Filled Case |
No |
| Pressure Gauge Type |
Commercial Pressure Gauge |
| Accuracy Grade |
ASME B40.100 Grade B |
| Primary Pressure Range |
0 to 60 |
| Primary Range |
0 to 60 |
| Sensor Type |
Bourdon Tube |
| Cleaned for Oxygen Service |
No |
| Primary Scale Units |
psi |
| Process Connection Type |
NPT |
| Includes Calibration Certificate |
No |
