Approved Vendor 3LZ29 Hose Clamp, Zinc-Plated Steel Band, Smooth, External Hex, 1 3/4 in – 2 3/64 in Dia., 7/8 in Band Wd

Approved Vendor KV3LZ29 Hose Clamp, Zinc-Plated Steel Band, Smooth, External Hex, 1 3/4 in – 2 3/64 in Dia., 7/8 in Band Wd

UPC: 190735481097 | Harmonization / Schedule B : 7326.90.8688

Country of Origin: China | Shipping Weight: 0.6 lbs

$7.25 - $7.25
$7.25
$7.25 - $7.25
$7.25

Hose Clamp, Band Material Steel, Band Material Finish Zinc-Plated, Band Thickness 0.256 in, Band Width 7/8 in, Clamp Maximum Inside Diameter 2 3/64 in, Clamp Minimum Inside Diameter 1 3/4 in, Install Torque 27 ft-lb, Screw Material Steel, Screw Material Finish Zinc-Plated, Clamp Type Double-Bolt Clamp, Fastener Housing Material Zinc-Plated Steel, For Use On Compressor Hoses, Low Pressure Couplings, Pneumatic Couplings, Hex Size 10 mm

Min. Hose Outside Dia. (In.) 1 3/4 in
Hose Inside Dia. (In.) 1 1/4 in
Max. Hose Outside Dia. (In.) 2 3/64 in
Hex Size 10 mm
Band Width 7/8 in
Band Thickness 0.256 in
For Maximum Outside Diameter 2 3/64 in
For Minimum Outside Diameter 1 3/4 in
Clamp Minimum Inside Diameter 1 3/4 in
Clamp Maximum Inside Diameter 2 3/64 in
MFR # 3LZ29
Zoro # G2653996
UPC # 190735481097
Country of Origin China
Clamp Type Double-Bolt Clamp
For Use With Low Pressure Couplings
Torque (Foot-Pounds) 27 ft-lb
Material of Construction Carbon Steel
Type Bolt-Close Clamp
Screw Material Finish Zinc-Plated
Maximum Operating Temperature 150 Degrees F
Application Air Pressure Applications
Grade General Purpose
Band Material Finish Zinc-Plated
Screw Material Steel
Band Type Smooth
For Use On Compressor Hoses, Low Pressure Couplings, Pneumatic Couplings
For Environment Agicultural, Drilling, Jackhammer, Mining, Washdown
Drive Type External Hex
Maximum Torque 27 ft-lb
Band Material Steel
Install Torque 27 ft-lb
Fastener Housing Material Zinc-Plated Steel
Reusable Clamp Yes
Features 2 Bolt
Minimum Operating Temperature -20 Degrees F
Country of Origin China (subject to change)
