Approved Vendor G15-60F-12X12 PTFE Sheet 0.0625 in

Approved Vendor G15-60F-12X12 PTFE Sheet, 0.0625 in Thick, 12 in x 12 in, White, Translucent

UPC: | Harmonization / Schedule B : 3920.10.0000

Country of Origin: United States | Shipping Weight: 0.71 lbs

$68.18 - $68.18
$68.18
$68.18 - $68.18
$68.18

PTFE Sheet, PTFE, Grade Standard, Plastic Length 12 in, Plastic Width 12 in, Plastic Thickness 0.0625 in, White, Plastic Clarity Translucent, Tensile Strength 1,500 psi, Impact Strength 3 ft-lb/in, Friction Coefficient 0.08, Water Absorption 0.01 Percent, Temperature Range -350 Degrees to 550 Degrees F, Plastic Density 13.24 lb/cu ft, Plastic Hardness 55D

Plastic Material PTFE
Plastic Color White
Max. Temp. (F) 500 Degrees F
Min. Temp. (F) -400 Degrees F
Color White
Plastic Properties Abrasion Resistant, Chemical/Corrosion Resistant, Electrical Applications, FDA Approved, Flame Retardant, Impact Resistant, Moisture Resistant, Non-Friction Surface, Oil Resistant, UV Tolerant, Wear Material
Tensile Strength 1,500 psi
Material Type Standard Grade
Standards AMS 3652, MIL-P-22241
Impact Strength 3 ft-lb/in
Plastic Grouping Sheet Stock
Material Color Family White
Thickness Tolerance +/-0.006 in
Operating Temp. Range -400 Degrees to 500 Degrees F
Material PTFE
UV Resistant Yes
Plastic Hardness Rating Medium Soft
Plastic Density 13.24 lb/cu ft
Friction Coefficient 0.08
Plastic Thickness Tolerance +/-0.006 in
Shape Square
Tensile Strength Rating Poor
Plastic Hardness 55D
Temperature Range -350 Degrees to 550 Degrees F
Impact Strength Rating Good
Plastic Clarity Translucent
Wear Factor Excellent
Weight 0.066 lb
Corrosion and Chemical Resistance Excellent
Machinability Not Rated
Maximum Temperature 550 Degrees F
Grade Standard
Minimum Temperature -350 Degrees F
Water Absorption Rating Excellent
Backing Type No Backing
Friction Rating Very Slippery
Water Absorption 0.01 %
Wear Rate 3.40 x 10^-4 cu mm/N-m
Flexural Modulus 0.04 GPa
Shore Hardness 55 Shore D
Scratch-Resistant Not Scratch-Resistant
Fabrication Molded
UV-Resistant UV-Resistant
Product Form Sheet
Light Transmission 9 %
Metal Detectable Not Metal Detectable
Coefficient of Thermal Expansion 13 x 10^-5
Dielectric Strength 80 kV/mm
Product Type Plastic Sheet
Elongation 200 %
Rockwell Hardness 50 HRR
Static-Resistant Not Static-Resistant
FDA Compliance Not FDA Compliant
Country of Origin United States
