Approved Vendor 60SQ112N034 Plug, 3/4 in, NPT Threaded, Hex Drive Solid Plug, 316 Stainless Steel, 300 psi, Class 150

Approved Vendor 60SQ112N034 Plug, 3/4 in, NPT Threaded, Hex Drive Solid Plug, 316 Stainless Steel, 300 psi, Class 150

UPC: | Harmonization / Schedule B : 7307.29.0090

Country of Origin: | Shipping Weight: 0.14 lbs

$7.16 - $7.16
$7.16
$7.16 - $7.16
$7.16

The ZORO SELECT - 60SQ112N034 is a stainless steel square head plug designed to close or seal the end of a threaded 3/4-inch pipe, coupling, or fitting. It features a 2-inch square head that provides a flat wrenching surface, facilitating installation and removal. Made from 316L stainless steel, this fitting is rated for Class 150 pressure, with a maximum operating pressure of 300 psi. It conforms to ANSI B1.20.1 standards, with a temperature range of -20 to 350 °F. Key Features: Material: 316L stainless steel Shape: Square head plug with a 2-inch square drive style Nominal pipe size: 3/4 inch Connection type: Male National Pipe Thread (MNPT) Pressure rating: Class 150, maximum operating pressure of 300 psi Temperature range: -20 to 350 °F Overall length: 30 mm Outside diameter: 3/4 inch Does not include pre-applied thread sealant or sealing components Non-magnetic

Pipe Size - Pipe Fitting 3/4"
Pipe Size (Fittings) 3/4"
Outside Diameter 3/4 in
Nominal Pipe Size 3/4 in
Overall Length 1 3/16 in
Thread Size 3/4"-14
Hex Size 23/32 in
Wire Rope Length 1 3/16 in
Length 1 3/16 in
MFR # 60SQ112N034
Zoro # G1180681
UPC # -
Country of Origin Multiple
Specific Fitting Shape Square Head Plug
Pipe Fitting Material 316 Stainless Steel
Fitting Connection Type MNPT
Fitting Schedule/Class Class 150
Basic Pipe Fitting Shape Plug
Basic Pipe Fitting Material Metal
Pipe Fitting Schedule/Class Class 150
Max. Pressure 300 psi
Standards ASTM A351
Specific Pipe Fitting Shape Square Head Plug
Fittings Sub-Category Plugs
Max. Steam Pressure 150 psi
Temp. Range -20 Degrees to 350 Degrees F
Magnetic No
Material Grade 316L
For Pipe Schedule Schedule 40
Fitting Side A Pipe Threading 14
Includes Pre-Applied Thread Sealant No
Maximum Operating Pressure 300 psi
Class Class 150
Plug Drive Style Hex
Includes Seal No
Color Silver
Minimum Operating Temperature -20 Degrees F
Thread Type NPT
Maximum Operating Temperature 350 Degrees F
Country of Origin Varies (subject to change)
